6.9.1.3 show ip vrrp interface
This command displays all configuration information of a virtual router configured on a specific interface.
Note that the information will be displayed only when the IP address of the specific interface is
configured.
Syntax
show ip vrrp interface {<slot/port> | vlan <vlan-id>} [<vrid>]
<slot/port> - Valid slot and port number separated by forward slashes.
<vrid> - Virtual router ID.
<vlan-id> - VLAN ID. The range of VLAN ID is 1 to 4093.
Default Setting
None
Command Mode
Privileged Exec
User Exec
Display Message
VRID: Represents the router ID of the virtual router.
Primary IP Address: This field represents the configured IP Address for the Virtual router.
VMAC address: Represents the VMAC address of the specified router.
Authentication type: Represents the authentication type for the specific virtual router.
Priority: Represents the priority value for the specific virtual router.
Configured Priority: The priority configured through the ip vrrp vrid priority 1-254 command.
Advertisement interval: Represents the advertisement interval for the specific virtual router.
Pre-Empt Mode: Is the preemption mode configured on the specified virtual router.
Pre-Empt Delay: How much time to be delayed before becoming the active router. It only performs
the delay when the preemption is first attempted.
Administrative Mode: Represents the status (Enable or Disable) of the specific router.
Accept Mode: When enabled, the VRRP Master can accept ping packets sent to one of the virtual
router's IP addresses.
State: Represents the state (Master/backup) of the specific virtual router
