6.10.2 Configuration Commands

6.10.2.1 ip policy route-map
Use this command to identify a route map to use for policy-based routing on an interface specified by
<route-map-name>. Policy-based routing is configured on the interface that receives the packets, not on
the interface from which the packets are sent.
When a route-map applied on the interface is changed, that is, if new statements are added to route-map
or match/set terms are added/removed from route-map statement, and also if route-map that is applied
on an interface is removed, route-map needs to be removed from interface and added back again in
order to have changed route-map configuration to be effective.
In order to disable policy based routing from an interface, use no form of this command.
Syntax
ip policy route-map <route-map-name>
no ip policy route-map <route-map-name>
Default Setting
None
Command Mode
Interface Config
6.10.2.2 ip prefix-list
To create a prefix list or add a prefix list entry, use the ip prefix-list command in Global Configuration
mode.
Prefix lists allow matching of route prefixes with those specified in the prefix list. Each prefix list includes
of a sequence of prefix list entries ordered by their sequence numbers. A router sequentially examines
each prefix list entry to determine if the route's prefix matches that of the entry. An empty or nonexistent
prefix list permits all prefixes. An implicit deny is assume if a given prefix does not match any entries of a
prefix list. Once a match or deny occurs the router does not go through the rest of the list.
A prefix list may be used within a route map to match a route's prefix using the command "match ip
address"
Up to 128 prefix lists may be configured. The maximum number of statements allowed in prefix list is 64.
To delete a prefix list or a statement in a prefix list, use the no form of this command. The command no
ip prefix-list list-name deletes the entire prefix list. To remove an individual statement from a prefix list,
you must specify the statement exactly, with all its options.
Syntax
ip prefix-list <list-name> {[seq number] {permit | deny} network/length [ge length] [le length] | renumber
renumber-interval first-statement-number}
no ip prefix-list <list-name> [seq number] {permit | deny} network/length [ge length] [le length]
