next-hop-address: The IP address of the next hop to which packets are output. It must be the
address of an adjacent router. A maximum of 16 next-hop IP addresses can be specified in this 'set'
clause.
6.10.2.18 set ip precedence
Use this command to set the three IP precedence bits in the IP packet header. With three bits, you have
eight possible values for the IP precedence; values 0 through 7 are defined. This command is used
when implementing QoS and can be used by other QoS services, such as weighted fair queuing (WFQ)
and weighted random early detection (WRED).
To reset the three IP precedence bits in the IP packet header to the default, use the no form of this
command.
Syntax
set ip precedence 0-7
no set ip precedence
Default Setting
None.
Command Mode
Route Map Config
Parameter
0: Sets the routine precedence.
1: Sets the priority precedence.
2: Sets the immediate precedence.
3: Sets the Flash precedence.
4: Sets the Flash override precedence.
5: Sets the critical precedence.
6: Sets the internetwork control precedence.
7: Sets the network control precedence.
6.10.2.19 set local-preference
To set the local preference of specific BGP routes, use the set local-preference command in Route
Map Configuration mode. The local preference is the first attribute used to compare BGP routes. Setting
the local preference can influence which route BGP selects as the best route.
When used in conjunction with a 'match as-path' or 'match ip address' command, this command can be
used to prefer routes that transit certain ASs or to make the local router a more preferred exit point to
certain destinations.
To remove a set command from a route map, use the no form of this command.
