Destination Unreachables: Displays whether ICMP Destination Unreachables may be sent
(enabled or disabled).
ICMP Redirects: Displays whether ICMP Redirects may be sent (enabled or disabled).
6.2.1.3 show ip interface vlan
This command displays all pertinent information about the VLAN routing interfaces.
Syntax
show ip interface vlan <1-4093>
Default Setting
None
Command Mode
Privileged Exec
User Exec
Display Message
Routing Interface Status: Determine the operational status of IPv4 routing Interface. The possible
values are Up or Down.
Primary IP Address: The primary IP address and subnet masks for the interface. This value
appears only if you configure it.
Method: Shows whether the IP address was configured manually or acquired from a DHCP server.
Secondary IP Address: One or more secondary IP addresses and subnet masks for the interface.
This value appears only if you configure it.
Helper IP Address: The helper IP addresses configured by the command "ip helper-address
(Interface Config)".
Routing Mode: The administrative mode of router interface participation. The possible values are
enable or disable. This value is configurable.
Administrative Mode: The administrative mode of the specified interface. The possible values of
this field are enable or disable. This value is configurable.
Forward Net Directed Broadcasts: Displays whether forwarding of network-directed broadcasts is
enabled or disabled. This value is configurable.
Proxy ARP: Displays whether Proxy ARP is enabled or disabled on the system.
Local Proxy ARP: Displays whether Local Proxy ARP is enabled or disabled on the interface.
Active State Displays whether the interface is active or inactive. An interface is considered active if
its link is up and it is in forwarding state.
Link Speed Data Rate: An integer representing the physical link data rate of the specified interface.
This is measured in Megabits per second (Mbps).
