13. To optimize the signal routing, the recommendation for one component placement is
shown in Figure
X-Ref Target - Figure A-7
cmd/addr/ctrl routing channel
Figure A-7: Component Placement Recommendations for One Component
Zynq-7000 AP SoC and 7 Series FPGAs MIS v4.1
UG586 November 30, 2016
A-7.
cmd/addr/ctrl
www.xilinx.com
Appendix A: General Memory Routing Guidelines
dq
dq routing channel
FPGA
UG583_c2_18_073014
