Table 3-28: DEBUG_PORT Signal Descriptions (Cont'd)
Signal
dbg_phy_wr_data[nCK_PER_CLK × 2 × DATA_WIDTH – 1:0]
dbg_phy_init_wr_only
dbg_phy_init_rd_only
dbg_byte_sel[CQ_BITS – 1:0]
dbg_bit_sel[Q_BITS – 1:0]
dbg_idel_up_all
dbg_idel_down_all
dbg_idel_up
dbg_idel_down
dbg_pi_f_inc
dbg_pi_f_dec
dbg_po_f_inc
Zynq-7000 AP SoC and 7 Series FPGAs MIS v4.1
UG586 November 30, 2016
Chapter 3: RLDRAM II and RLDRAM 3 Memory Interface Solutions
Direction Description
Output
Input
Input
Input
Input
Input
Input
Input
Input
Input
Input
Input
www.xilinx.com
Data being written that is used for debug
with the Vivado logic analyzer feature.
When this input is High, the state
machine in the rld_phy_write_init_sm
module keeps issuing write commands
for Stage 1 data to the RLDRAM II. This
can be used to verify write timing, for
measuring the DK to DQ timing
relationship at the memory using an
oscilloscope. This signal must be Low for
normal operation.
When this input is High, the state
machine in the rld_phy_write_init_sm
module keeps issuing read commands
for Stage 1 read calibration. This is useful
to probe the signals on the PCB and look
for any SI issues or verify the previous
write command occurred properly. This
signal must be Low for normal operation.
This input selects the corresponding
byte lane and you set the phaser/IDELAY
tap controls.
This input selects the corresponding bit
lane and you set the IDELAY tap controls.
It also controls which read data signals
are presented to you for debug
(dbg_rd_data_rd and dbg_rd_data_fd).
This input increments all IDELAY tap
values for the entire bus.
This input decrements all IDELAY tap
values for the entire bus.
This input increments all IDELAY tap
values for a single bit, selected by
dbg_bit_sel.
This input decrements all IDELAY tap
values for a single bit, selected by
dbg_bit_sel.
This signal increments the PHASER_IN
generated ISERDES clk that is used to
capture rising data.
This signal decrements the PHASER_IN
generated ISERDES clk that is used to
capture rising data.
This signal increments the PHASER_OUT
generated OSERDES clk that is used to
capture falling data.
