Table 1-74: DDR2/DDR3 Debug Signals (Cont'd)
Signal Name
dbg_pi_phase_locked_phy4lanes
dbg_pi_dqs_found_lanes_phy4lanes
dbg_rd_data_offset
dbg_cal1_state_r
dbg_cal1_cnt_cpt_r
dbg_mux_rd_rise0_r
dbg_mux_rd_fall0_r
dbg_mux_rd_rise1_r
dbg_mux_rd_fall1_r
dbg_mux_rd_rise2_r
dbg_mux_rd_fall2_r
dbg_mux_rd_rise3_r
dbg_mux_rd_fall3_r
dbg_rdlvl_pat_data_match_r
Zynq-7000 AP SoC and 7 Series FPGAs MIS v4.1
UG586 November 30, 2016
Chapter 1: DDR3 and DDR2 SDRAM Memory Interface Solution
Description
Signifies which of the PHASER_IN lanes has achieved lock. It is a 12-bit
bus, three nibble data.
Each nibble corresponds to a bank information. Uppermost Data or
Address/Control byte group selected bank is referred to as Bank0, this
corresponds to nibble 0 or Bits[3:0] of the bus. Numbering of banks is
0, 1, and 2 from top to bottom. Bank1 corresponds to nibble 1 or
Bits[7:4] of the bus. Bank2 corresponds to nibble 2 or Bits[11:8] of the
bus.
LSB to MSB bits in each nibble corresponds to T3 to T0 byte lane
information of the corresponding bank.
For example, Nibble 0, Bit[3] corresponds to T0 byte lane, Bit[2]
corresponds to T1 byte lane, Bit[1] corresponds to T2 byte lane, Bit[0]
corresponds to T3 byte lane information.
Signifies which of the PHASER_IN lanes is able to find the DQS. It is a
12-bit bus, three nibble data.
Each nibble corresponds to a bank information. Uppermost Data or
Address/Control byte group selected bank is referred to as Bank0, this
corresponds to nibble 0 or Bits[3:0] of the bus. Numbering of banks is
0, 1, and 2 from top to bottom. Bank1 corresponds to nibble 1 or
Bits[7:4] of the bus. Bank2 corresponds to nibble 2 or Bits[11:8] of the
bus.
LSB to MSB bits in each nibble corresponds to T3 to T0 byte lane
information of the corresponding bank.
For example, Nibble 0, Bit[3] corresponds to T0 byte lane, Bit[2]
corresponds to T1 byte lane, Bit[1] corresponds to T2 byte lane, Bit[0]
corresponds to T3 byte lane information.
Read data offset found during calibration.
State machine variable for MPR and Read Leveling Stage 1. States can
be decoded in the ddr_phy_rdlvl.v module.
Signifies the byte that failed MPR Read Leveling or Read Leveling
Stage 1.
Data pattern received on rising edge 0.
Data pattern received on falling edge 0.
Data pattern received on rising edge 1.
Data pattern received on falling edge 1.
Data pattern received on rising edge 2.
Data pattern received on falling edge 2.
Data pattern received on rising edge 3.
Data pattern received on falling edge 3.
Asserts when the valid pattern is detected on the data and is found to
match with the expected pattern sent during read leveling.
