Figure 1-68 shows an initial DQS to CK alignment case for component interfaces. The
assumption is that component interfaces also use the fly-by topology, thereby requiring
write leveling.
X-Ref Target - Figure 1-67
Figure 1-67: UDIMM/RDIMM DQS-to-CK Initial Alignment
X-Ref Target - Figure 1-68
The PHASER_OUT fine and coarse delay provides 1 t
additional clock cycle of delay required to align to the correct CK edge is achieved using the
coarse delay line. If the total delay required is over one clock cycle, the div_cycle_delay
input to the PHASER_OUT block need not be asserted because a circular buffer was added
to the PHASER_OUT block.
Zynq-7000 AP SoC and 7 Series FPGAs MIS v4.1
UG586 November 30, 2016
Chapter 1: DDR3 and DDR2 SDRAM Memory Interface Solution
Figure 1-68: Component DQS-to-CK Initial Alignment
www.xilinx.com
worth of delay for write leveling. The
CK
