Date Version
06/19/2013 2.0
Zynq-7000 AP SoC and 7 Series FPGAs MIS v4.1
UG586 November 30, 2016
• Vivado Design Suite release only for MIG v2.0. Revision number advanced to 2.0 to
align with core version number.
Chapter 1
• Updated ChipScope to Vivado logic analyzer, VIO, and ILA.
• Updated ui_clk and ui_clk_sync_rst descriptions in Table 1-17 User Interface.
• Updated ui_clk and ui_clk_sync_rst descriptions.
• Added Ordering Modes in Reordering section and added modes in Table 1-91.
• Updated ECC enable in AXI4 Slave Interface Block section.
• Updated Read Priority (RD_PRI) section.
• Updated Table 1-19 AXI4 Slave Interface Parameters, C_S_AXI_ADDR_WIDTH value
and descriptions.
• Added Write Priority description.
• Updated PHASER_IN DQSFOUND Calibration section.
• Removed Downsizing Option.
• Added DM in DQ descriptions.
• Added Dynamic Calibration and Periodic Read Behavior section.
• Added Vivado Lab Tools section.
• Added AR 54025 for Vivado.
• Updated Debugging PHASER_IN DQSFOUND Calibration Failures
(dbg_pi_dqsfound_err = 1) section.
Chapter 2
• Updated ChipScope to Vivado logic analyzer, VIO, and ILA.
• Added Fixed Latency Mode description in Controller Options section.
• Removed qdr_qvld in Table 2-12 Physical Interface Signals.
• Updated Figure 2-26 Four-Word Burst Length Memory Device Protocol.
• Updated Output Architecture section in Write Path.
• Added Write Calibration section.
• Removed QVLD.
• Updated Table 2-20 Write Init Debug Signal Map.
• Updated Tables 2-21 and 2-22 Read Stage 1 and Stage 2 Debug Signal Map tables.
Chapter 3
• Updated ChipScope to Vivado logic analyzer, VIO, and ILA.
• Removed rld_qvld in Table 3-13 Physical Interface Signals.
• Removed QVLD and QVLD_MAP in Table 3-16 RLDRAM II Memory Interface Solution
Pinout Parameters.
• Removed QVLD.
• Updated descriptions in Manual Pinout Changes section.
• Added new calibration description in Calibration section.
• Updated Table 3-26 Physical Layer Simple Status Bus Description Defined in the
rld_phy_top Module.
