Xilinx Zynq-7000 User Manual page 524

11. Click IP Catalog on the Project Manager window to open the IP catalog window. The IP
catalog window appears on the right side panel (see
circle).
12. The MIG tool exists in the Memories & Storage Elements > Memory Interface
Generators section of the IP catalog window
Search tool bar for the string "MIG."
X-Ref Target - Figure 4-12
Figure 4-12: IP Catalog Window – Memory Interface Generator
Zynq-7000 AP SoC and 7 Series FPGAs MIS v4.1
UG586 November 30, 2016
Chapter 4: LPDDR2 SDRAM Memory Interface Solution
(Figure
www.xilinx.com
Figure 4-12, highlighted in a red
4-12) or you can search from the
Send Feedback
524
