Table 4-26: Embedded 7 Series FPGAs Memory Solution Configuration Parameters (Cont'd)
Parameter
SYSCLK_TYPE
REFCLK_TYPE
CLKIN_PERIOD
CLKFBOUT_MULT
CLKOUT0_DIVIDE,
CLKOUT1_DIVIDE,
CLKOUT2_DIVIDE,
CLKOUT3_DIVIDE
DIVCLK_DIVIDE
USE_DM_PORT
CK_WIDTH
DQ_CNT_WIDTH
DRAM_TYPE
DRAM_WIDTH
Zynq-7000 AP SoC and 7 Series FPGAs MIS v4.1
UG586 November 30, 2016
Chapter 4: LPDDR2 SDRAM Memory Interface Solution
Description
This parameter indicates whether the
system uses single-ended system clocks,
differential system clocks, or is driven from
an internal clock (No Buffer). Based on the
selected CLK_TYPE, the clocks must be
placed on the correct input ports. For
differential clocks, sys_clk_p/sys_clk_n must
be used. For single-ended clocks, sys_clk_i
must be used. For the No Buffer option,
sys_clk_i, which appears in port list, needs to
be driven from an internal clock.
This parameter indicates whether the
system uses single-ended reference clocks,
differential reference clocks, is driven from
an internal clock (No Buffer), or can connect
system clock inputs only (Use System Clock).
Based on the selected CLK_TYPE, the clocks
must be placed on the correct input ports.
For differential clocks, clk_ref_p/clk_ref_n
must be used. For single-ended clocks,
clk_ref_i must be used. For the No Buffer
option, clk_ref_i, which appears in the port
list, needs to be driven from an internal
clock. For the Use System Clock option,
clk_ref_i is connected to the system clock in
the user design top module.
Input clock period.
PLL voltage-controlled oscillator (VCO)
multiplier. This value is set by the MIG tool
based on the frequency of operation.
VCO output divisor for PLL outputs. This
value is set by the MIG tool based on the
frequency of operation.
PLLE2 VCO divisor. This value is set by the
MIG tool based on the frequency of
operation.
This is the enable data mask option used
during memory write operations.
This is the number of CK/CK# outputs to
memory.
This is ceil(log2(DQ_WIDTH)).
This is the supported memory standard for
the Memory Controller.
This is the DQ bus width per DRAM
component.
