• Two CK early write pattern read back – 55AA9966BB11EE44
• One CK late write pattern read back – XXXXFF00AA5555AA
Calibration cannot correct for this pattern. This pattern indicates that the trace
°
delays are incorrect where CK is incorrectly shorter than DQS.
If none of the above patterns are detected during reads, the algorithm assumes the MPR
read leveling IDELAY settings are incorrect and the IDELAYs for the DQ bits associated with
that byte are set to 0. MPR read leveling could have an incorrect IDELAY setting because
with the "01010101" or "10101010" pattern, it is not possible to differentiate between clock
cycles.
Debug
If dbg_wrcal_err is asserted, denoting a Write Calibration failure, use dbg_wrcal_err
= R as the trigger and observe the following debug signals. If dbg_wrcal_done asserted
but the results of this stage need to be analyzed, use dbg_wrcal_done as the trigger.
Table 1-79: Debug Signals of Interest for Write Calibration
Signal Name
dbg_wrcal_start
dbg_wrcal_done
dbg_wrcal_err
pat_data_match
pat_data_match_valid
wrcal_dqs_cnt
cal2_state
not_empty_wait_cnt
early1_data
early2_data
dbg_wcal_mux_rd_rise0_r Data pattern received on rising edge 0.
dbg_wcal_mux_rd_fall0_r
dbg_wcal_mux_rd_rise1_r Data pattern received on rising edge 1.
Zynq-7000 AP SoC and 7 Series FPGAs MIS v4.1
UG586 November 30, 2016
Chapter 1: DDR3 and DDR2 SDRAM Memory Interface Solution
Description
Signifies the start of the Write Calibration stage of calibration.
Signifies successful completion of the Write Calibration stage of calibration.
Signifies Write Calibration exhibited errors and did not complete.
Asserts when the valid pattern is detected.
Toggles when the correct pattern is detected.
Current DQS group being calibrated in Write Calibration. When dbg_wrcal_start
asserts, wrcal_dqs_cnt is 0. The algorithm sequentially steps through the DQS byte
groups checking to see if the read data pattern matches the expected
FF00AA5555AA9966 pattern. If the pattern matches, wrcal_dqs_cnt increments by 1.
The algorithm then starts looking for the correct data pattern on the next byte until
it reaches DQS_WIDTH – 1 or a data byte group fails due to the data pattern not being
detected properly. The wrcal_dqs_cnt stays at DQS_WIDTH – 1 after dbg_wrcal_done
signal is asserted.
Write Calibration state machine variable.
Count value during write calibration pattern detection. Maximum count is 0x1F. If
count reaches 0x1F, write calibration fails with the assertion of dbg_wrcal_err.
Asserts when the pattern detected is one CK clock cycle early. When this is asserted,
the write leveling algorithm moves the CK clock one cycle. After CK is moved, the write
calibration algorithm restarts pattern detection.
Asserts when the pattern detected is two CK clock cycles early. When this is asserted,
the write leveling algorithm moves the CK clock two cycles. After CK is moved, the
write calibration algorithm restarts pattern detection.
Data pattern received on falling edge 0.
