Table 1-23: ECC Control Register Map (Cont'd)
Address Offset Register Name
0x2C0 UE_FFA[31:0]
0x2C4 UE_FFA[63:32]
0x300 FI_D[31:0]
0x304 FI_D[63:32]
0x308 FI_D[95:64]
0x30C FI_D[127:96]
(3)
0x380 FI_ECC
Notes:
1. Data bits 64–127 are only enabled if the DQ width is 144 bits.
2. Reporting address bits 63–32 are only available if the address map is > 32 bits.
3. FI_D* and FI_ECC* are only enabled if ECC_TEST parameter has been set to 1.
AXI4-Lite Slave Control/Status Register Map Detailed Descriptions
ECC_STATUS
This register holds information on the occurrence of correctable and uncorrectable errors.
The status bits are independently set to 1 for the first occurrence of each error type. The
status bits are cleared by writing a 1 to the corresponding bit position; that is, the status bits
can only be cleared to 0 and not set to 1 using a register write. The ECC Status register
operates independently of the ECC Enable Interrupt register.
Table 1-24: ECC Status Register Bit Definitions
Bits Name
31:2 Reserved
1 CE_STATUS
0 UE_STATUS
ECC_EN_IRQ
This register determines if the values of the CE_STATUS and UE_STATUS bits in the ECC
Status Register assert the Interrupt output signal (ECC_Interrupt). If both CE_EN_IRQ and
Zynq-7000 AP SoC and 7 Series FPGAs MIS v4.1
UG586 November 30, 2016
Chapter 1: DDR3 and DDR2 SDRAM Memory Interface Solution
Access Default
Type Value
R 0x0
(2)
R 0x0
(0x2C8–0x2FC) Reserved
(3)
W 0x0
(3)
W 0x0
(1)(3)
W 0x0
(1)(3)
W 0x0
(0x340–0x37C) Reserved
W 0x0
Core Reset
Description
Access Value
RSVD – Reserved
If 1, a correctable error has occurred. This bit is cleared when a 1
R/W 0
is written to this bit position.
If 1, an uncorrectable error has occurred. This bit is cleared when
R/W 0
a 1 is written to this bit position
www.xilinx.com
Description
Uncorrectable Error First Failing Address
Uncorrectable Error First Failing Address
Fault Inject Data Register
Fault Inject Data Register
Fault Inject Data Register
Fault Inject Data Register
Fault Inject ECC Register
