Table 2-12: 7 Series FPGAs QDR II+ SRAM Memory Interface Solution Configurable Parameters (Cont'd)
Parameter
SYSCLK_TYPE
REFCLK_TYPE
DIFF_TERM
CLKIN_PERIOD
CLKFBOUT_MULT
CLKOUT0_DIVIDE,
CLKOUT1_DIVIDE,
CLKOUT2_DIVIDE,
CLKOUT3_DIVIDE
CLKOUT0_PHASE
DIVCLK_DIVIDE
SIM_BYPASS_INIT_CAL
Zynq-7000 AP SoC and 7 Series FPGAs MIS v4.1
UG586 November 30, 2016
Description
This parameter indicates whether the system uses
single-ended system clocks, differential system clocks, or is
driven from an internal clock (No Buffer). Based on the
selected CLK_TYPE, the clocks must be placed on the
correct input ports. For differential clocks,
sys_clk_p/sys_clk_n must be used. For single-ended clocks,
sys_clk_i must be used. For the No Buffer option, sys_clk_i,
which appears in the port list, needs to be driven from the
internal clock.
This parameter indicates whether the system uses
single-ended reference clocks, differential reference clocks,
is driven from an internal clock (No Buffer), or can connect
system clock inputs only (Use System Clock). Based on the
selected CLK_TYPE, the clocks must be placed on the
correct input ports. For differential clocks,
clk_ref_p/clk_ref_n must be used. For single-ended clocks,
clk_ref_i must be used. For the No Buffer option, clk_ref_i,
which appears in port list, needs to be driven from an
internal clock. For the Use System Clock option, clk_ref_i is
connected to the system clock in the user design top
module.
This parameter indicates whether differential or
non-differential termination is required for the system clock
inputs.
Input clock period.
PLL voltage-controlled oscillator (VCO) multiplier. This
value is set by the MIG tool based on the frequency of
operation.
VCO output divisor for PLL outputs. This value is set by the
MIG tool based on the frequency of operation.
Phase of PLL output CLKOUT0. This value is set by the MIG
based on the banks selected for memory interface pins and
the frequency of operation.
PLLE2 VCO divisor. This value is set by the MIG tool based
on the frequency of operation.
This simulation only parameter is used to speed up
simulations.
www.xilinx.com
Chapter 2: QDR II+ Memory Interface Solution
Send Feedback
Options
DIFFERENTIAL
SINGLE_ENDED
NO_BUFFER
DIFFERENTIAL
SINGLE_ENDED
NO_BUFFER
USE_SYSTEM_CLOCK
TRUE
FALSE
FAST
OFF
338
