Debugging PRBS Read Leveling Failures
Calibration Overview
This stage of calibration was added in MIG 7 series v1.7 and determines the read data valid
window using complex pattern that is written once and read back from the DDR3 SDRAM.
Debug
Table 1-81: Debug Signals of Interest for PRBS Read Leveling Calibration
Debug Signal
left_edge_pb
left_loss_pb
right_edge_pb
right_gain_pb
prbs_dqs_cnt_r
prbs_rdlvl_start
prbs_rdlvl_done
compare_err_r0
compare_err_r1
compare_err_r2
compare_err_r3
compare_err_f0
compare_err_f1
compare_err_f2
compare_err_f3
compare_err
prbs_dqs_tap_cnt_r
pi_counter_read_val
Zynq-7000 AP SoC and 7 Series FPGAs MIS v4.1
UG586 November 30, 2016
Chapter 1: DDR3 and DDR2 SDRAM Memory Interface Solution
Signal Description
Signifies PHASER_IN fine tap value of starting valid read window (left
edge) for each bit in a byte. left_edge_pb[5:0] is the left edge of Bit[0]
and left_edge_pb[47:42] is the left edge of Bit[7].
Signifies the loss in aggregate window size caused by left edge
change for each bit in a byte. If left edge change of the bit does not
affect the valid window, it is set to "0," left_loss_pb[1:0] is for Bit[0],
and left_loss_pb[15:14] is for Bit[7].
Signifies PHASER_IN fine tap value of ending valid read window (right
edge) for each bit in a byte. right_edge_pb[5:0] is right edge of Bit[0]
and right_edge_pb[47:42] is the right edge of Bit[7].
Signifies the gain in aggregate valid window caused by right edge
change for each bit in a byte. If right edge change of the bit does not
affect the valid window, it is set to "0," right_gain_pb[1:0] is for Bit[0],
and right_gain_pb[15:14] is for Bit[7].
Signifies the current DQS byte group being calibrated during PRBS
Read Leveling. Use VIO dbg_dqs to select the byte group.
Signifies the start of PRBS Read Leveling calibration.
Signifies the successful completion of PRBS Read Leveling.
Signifies data mismatch on first rising edge data comparison.
Signifies data mismatch on second rising edge data comparison.
Signifies data mismatch on third rising edge data comparison.
Signifies data mismatch on forth rising edge data comparison.
Signifies data mismatch on first falling edge data comparison.
Signifies data mismatch on second falling edge data comparison.
Signifies data mismatch on third falling edge data comparison.
Signifies data mismatch on forth falling edge data comparison.
Signifies data comparison failure due to a read data pattern
Signifies the internal counter which tracks PHASER_IN fine tap
movement.
Signifies DQS PHASER_IN fine tap setting.
