Single Address Mode - Hitachi H8S/2378, H8S/2378R Series Hardware Manual

Repeat mode setting
Set DMABCRH
Set transfer source
and transfer destination
addresses
Set number of transfers
Set DMACR
Read DMABCRL
Set DMABCRL
Repeat mode
Figure 7.8 Example of Repeat Mode Setting Procedure
7.5.5

Single Address Mode

Single address mode can only be specified for channel B. This mode can be specified by setting
the SAE bit in DMABCRH to 1 in short address mode.
Rev. 1.0, 09/01, page 280 of 904
[1] Set each bit in DMABCRH.
• Clear the FAE bit to 0 to select short address
mode.
• Specify enabling or disabling of internal
interrupt clearing with the DTA bit.
[1]
[2] Set the transfer source address and transfer
destination address in MAR and IOAR.
[3] Set the number of transfers in both ETCRH and
ETCRL.
[2]
[4] Set each bit in DMACR.
• Set the transfer data size with the DTSZ bit.
• Specify whether MAR is to be incremented or
decremented with the DTID bit.
[3]
• Set the RPE bit to 1.
• Specify the transfer direction with the DTDIR
bit.
• Select the activation source with bits DTF3 to
DTF0.
[4]
[5] Read the DTE bit in DMABCRL as 0.
[6] Set each bit in DMABCRL.
• Clear the DTIE bit to 0.
[5]
• Set the DTE bit to 1 to enable transfer.
[6]
