Table 20-13. BRGCn Field Descriptions (Continued)
Bits Name
18 ATB Autobaud. Selects autobaud operation for BRGn on the corresponding RXDn. ATB must remain zero
until the SCC receives the three Rx clocks. Then the user must set ATB to obtain the correct baud rate.
After the baud rate is obtained and locked, it is indicated by setting AB in the UART event register. See
Section 20.4.2, "Autobaud Operation on the SCC UART."
0 Normal operation of the BRG.
1 When RXD goes low, the BRG determines the length of the start bit and synchronizes the BRG to
the actual baud rate.
19–30 CD Clock divider. CD presets an internal 12-bit counter that is decremented at the DIV16 output rate.
When the counter reaches zero, it is reloaded with CD. CD = 0xFFF produces the minimum clock rate
for BGRO (divide by 4,096); CD = 0x000 produces the maximum rate (divide by 1). When dividing by
an odd number, the counter ensures a 50% duty-cycle by asserting the terminal count once on clock
low and next on clock high. The terminal count signals counter expiration and toggles the clock. See
Section 20.4.3, "UART Baud Rate Examples."
31 DIV1 Divide-by-16. Selects a divide-by-1 or divide-by-16 prescaler before reaching the clock divider. See
6 Section 20.4.3, "UART Baud Rate Examples."
0 Divide by 1.
1 Divide by 16.

20.4.2 Autobaud Operation on the SCC UART

During the autobaud process, the SCC UART deduces the baud rate of its received character
stream by examining the received pattern and its timing. A built-in autobaud control
function automatically measures the length of a start bit and modifies the baud rate
accordingly.
If the autobaud bit BRGCn[ATB] is set, the autobaud control function starts searching for
a low level on the corresponding RXDn input, which it assumes marks the beginning of a
start bit, and begins counting the start bit length. During this time, the BRG output clock
toggles for 16 BRG clock cycles at the BRG source clock rate and then stops with BRGOn
in the low state.
When RXDn goes high again, the autobaud control block rewrites BRGCn[CD, DIV16] to
the divide ratio found, which at high baud rates may not be exactly the final rate desired (for
example, 56,600 may result rather than 57,600). An interrupt can be enabled in the UART
SCC event register to report that the autobaud controller rewrote BRGCn. The interrupt
handler can then adjust BRGCn[CD, DIV16] (see Table 20-14) for accuracy before the first
character is fully received, ensuring that the UART recognizes all characters.
After a full character is received, the software can verify that the character matches a
predefined value (such as 'a' or 'A'). Software should then check for other characters (such
as 't' or 'T') and program the preferred parity mode in the UART's protocol-specific mode
register (PSMR).
Note that the SCC associated with this BRG must be programmed to UART mode and
select the 16× option for TDCR and RDCR in the general SCC mode register (GSMR_L).
Input frequencies such as 1.8432, 3.68, 7.36, and 14.72 MHz should be used. The SCC
Description
Chapter 20. Serial Interface
Baud Rate Generators (BRGs)
