RM0090
The application can use the following formula to calculate the value of TRDT:
4 × AHB clock + 1 PHY clock = (2 clock sync + 1 clock memory address + 1 clock
memory data from sync RAM) + (1 PHY clock (next PHY clock MAC can sample the 2
clock FIFO outputs)

Figure 398. TRDT max timing case

tkn_rcvd
dsynced_tkn_rcvd
spr_read
spr_addr
spr_rdata
srcbuf_push
srcbuf_rdata
31.13.9

OTG programming model

The OTG_HS controller is an OTG device supporting HNP and SRP. When the core is
connected to an "A" plug, it is referred to as an A-device. When the core is connected to a
"B" plug it is referred to as a B-device. In host mode, the OTG_HS controller turns off V
to conserve power. SRP is a method by which the B-device signals the A-device to turn on
V power. A device must perform both data-line pulsing and V
BUS
detect either data-line pulsing or V
device negotiates and switches to host role. In Negotiated mode after HNP, the B-device
suspends the bus and reverts to the device role.
0ns
1 2
HCLK
PCLK
Doc ID 018909 Rev 4
USB on-the-go high-speed (OTG_HS)
50ns 100ns
3 4
A1
5 Clocks
pulsing for SRP. HNP is a method by which the B-
BUS
150ns 200ns
5 6 7
D1
D1
pulsing, but a host can
BUS
8
ai15680
BUS
1310/1422
