Interrupts and events
8.3.5

Software interrupt event register (EXTI_SWIER)

Address offset: 0x10
Reset value: 0x0000 0000
31 30 29
15 14 13
SWIER SWIER SWIER SWIER
15 14 13
rw rw rw
Bits 31:23
Bits 22:0 SWIERx: Software Interrupt on line x
8.3.6

Pending register (EXTI_PR)

Address offset: 0x14
Reset value: undefined
31 30 29
15 14 13
PR15 PR14 PR13 PR12
rc_w1 rc_w1 rc_w1 rc_w1
Bits 31:23
Bits 22:0 PRx: Pending bit
174/1378
28 27 26 25
Reserved
12 11 10 9
SWIER SWIER SWIER
12 11 10 9
rw rw rw rw
Reserved, must be kept at reset value (0).
Writing a 1 to this bit when it is at 0 sets the corresponding pending bit in EXTI_PR. If the
interrupt is enabled on this line on the EXTI_IMR and EXTI_EMR, an interrupt request is
generated.
This bit is cleared by clearing the corresponding bit in EXTI_PR (by writing a 1 to the bit).
28 27 26 25
Reserved
12 11 10 9
PR11 PR10 PR9
rc_w1 rc_w1 rc_w1
Reserved, must be kept at reset value (0).
0: No trigger request occurred
1: selected trigger request occurred
This bit is set when the selected edge event arrives on the external interrupt line. This bit is
cleared by writing a 1 to the bit or by changing the sensitivity of the edge detector.
24 23 22
SWIER SWIER
22
rw
8 7 6
SWIER SWIER SWIER SWIER
8 7 6
rw rw rw
24 23 22
PR22 PR21
rc_w1 rc_w1
8 7 6
PR8 PR7 PR6 PR5
rc_w1 rc_w1 rc_w1 rc_w1
RM0033 Rev 8
21 20 19 18
SWIER SWIER SWIER
21 20 19 18
rw rw rw rw
5 4 3 2
SWIER SWIER SWIER
5 4 3 2
rw rw rw rw
21 20 19 18
PR20 PR19 PR18
rc_w1 rc_w1 rc_w1
5 4 3 2
PR4 PR3 PR2
rc_w1 rc_w1 rc_w1
RM0033
17 16
SWIER SWIER
17 16
rw rw
1 0
SWIER SWIER
1 0
rw rw
17 16
PR17 PR16
rc_w1 rc_w1
1 0
PR1 PR0
rc_w1 rc_w1
