Screen Reference
ISDN Numbering — Public/ Unknown
Ext Code
Allows for groups of extensions to be administered.
NOTE:
When 0 alone is entered, the Ext Len field must be 1 and the DDD number must be
10-digits.
Valid entries
0 to 9 or blank
attd
Ext Len
Specifies the number of digits the extension can have.
Valid entries
0 to 7 or blank
Total CPN Len
Valid entries
0 to 15 or blank
Trk Grp(s)
Communication Manager generates the station's identification number if there is an entry in the Ext Code
field, and this field is administered with the trunk group number carrying the call.
Valid entries
1 to 7 digits
blank
1000
Usage
The can be up to 7-digits long depending on the
Ext Code
field entry. The entry cannot be greater than the
entry. For example, in the case of a 4-digit
Ext Code of 12 is the equivalent of all extensions of the screen
12xx, excluding any explicitly listed longer codes. If a code of 123
is also listed, the 12 code is equivalent of all extensions of the
screen 12xx except extensions of the screen 123x. The coding
precludes having to list all the applicable 12xx extensions.
For attendant
Usage
Corresponds to the extension lengths allowed by the
dial plan.
Usage
Enter the total number of digits to send.
Usage
Enter the valid administered ISDN trunk-group number or a range
of group numbers. For example, if trunk groups 10 through 24 use
the same CPN Prefix, enter 10-24.
The identification numbers are not dependent on which trunk group
the call is carried.
Administrator's Guide for Avaya Communication Manager
Ext Len
field
Ext Len
Ext Len field entry, an
