Avaya Communication Manager Administrator's Manual page 780

Screen Reference
DS1 Circuit Pack
Figure 168: DS1 Circuit Pack screen for Channel Associated Signaling
add ds1 xxxxxx
Signaling Mode: CAS
Interface Companding: mulaw
MAINTENANCE PARAMETERS
Slip Detection? n
Bit Rate
Use this field to select the maximum transmission rate for DS1 circuit packs that support either T-1 or
E-1 service. For circuit packs that only support one of these services, the field is a display-only field.
NOTE:
Once an add ds1 operation is complete (that is, the DS1 screen has been submitted) you
can't change the
ds1 command. Then use the add ds1 command to administer the circuit pack again.
You'll have to re-enter all the information for the circuit pack.
TN464C (and later release) circuit packs have an option switch that must be set to match
the entry in the
Valid entries
1.544
2.048
780
DS1 CIRCUIT PACK
Location: 01A13
Bit Rate: 2.048
Interconnect: pbx
Idle Code: 11111111
field with a change ds1 command. Instead, execute a remove
Bit Rate
field.
Bit Rate
Usage
Use for T-1 service.
Use for E-1 service.
Administrator's Guide for Avaya Communication Manager
Name: _______________
Line Coding: cmi
Country Protocol: 3
Page 1 of 2
November 2003
