Avaya Communication Manager Administrator's Manual page 729

CTI Link
A display-only field indicating the CTI link number.
Valid entries
1-8
1-16
Extension
This field displays the extension for this link.
Type
For each link that you want to add to your system, you must specify the CTI link type.
Valid entries
ADJLK
ADJ-IP
ASAI
ASAI-IP
Port
Appears when the
Valid entries
01 through 44
(DEFINITY R)
01 through 03
(DEFINITY SI)
A through E
01 through 20
01 through 32
x
Administrator's Guide for Avaya Communication Manager
November 2003
Usage
S8100 Media Server with a CMC1
Avaya Communication Manager on a DEFINITY Server CSI
DEFINITY G3i
S8300 Media Server
Avaya Communication Manager on a DEFINITY Server R
S8700 Multi-Connect
Usage
For ASAI links not used by co-resident DLG.
For ASAI adjunct links used by co-Resident DLG.
For ASAI adjunct links not used by co-resident DLG.
For ASAI links used by co-Resident DLG.
Type field is ASAI or ADJLK. Enter 7 characters to specify a port, or an x.
Usage
First and second numbers are the cabinet number
Third character is the carrier
Fourth and fifth characters are the slot number
Sixth and seventh characters are the circuit number
Indicates that there is no hardware associated with the port
assignment. Use for AWOH.
Screen Reference
CTI Link
729
