Goodrive350-19 Series VFD for Crane
Function
Name
code
Mechanical
P93.09
transmission ratio
P93.10 Suspension ratio
Rope length
P93.11
compensation
P93.12 Cable diameter
P93.15 Pulley diameter
Height status check
Total height
P93.17
measured
P93.18 Measured height 1
P94.05 Measured height
High bits of height
P94.06 measuring pulse
count value
Low bits of height
P94.07 measuring pulse
count value
Description
the height.)
0.01–300.00
1–4
0.00–50.00m
0.1–100.0m
100.0–2000.0mm
0.00–655.35m (Total height measured from the
upward limit position to the downward limit position)
-50.00–655.35m (Using the downward limit position
as the reference point)
0.00–655.35m (hook lowering distance)
0–65535
0–65535
