INVT Goodrive350-19 Series Operation Manual page 269

Goodrive350-19 Series VFD for Crane
Function
Name
code
resolver
P18.21 Resolver angle
Closed-loop SM
P18.22
pole angle
P18.23
SW 2
High-order bit of
P18.24 count value of
pulse reference
Low-order bit of
P18.25
count value of
pulse reference
PG card detected
P18.26
speed
Encoder UVW
P18.27
sectors
Encoder PPR
P18.28
display
Angle
P18.29 compensation
value of SM
Z pulse angle of
P18.30
SM
Z pulse value of
P18.31
pulse reference
Main control board
P18.32 measured value of
pulse reference
PG card measured
P18.33 value of pulse
reference
Present encoder
P18.34
filter width
P18.35 8K test duration
Description
Range: 0–65535
Pole position angle read by the resolver-type
encoder.
Setting range: 0.00–359.99
Present pole position.
Setting range: 0.00–359.99
0–65535
Indicates the pulse command (A2, B2) count
value. The count value is accumulated only if
the VFD is powered on.
Range: 0–65535
Indicates the pulse command (A2, B2) count
value. The count value is accumulated only if
the VFD is powered on.
Range: 0–65535
-3276.8–3276.7Hz
0–7
0–65535
-180.0–180.0
0.00–655.35
0–65535
-3276.8–3276.7Hz
-3276.8–3276.7Hz
0–63
0–65535
-257-
Function parameters
Default Modify
●
0.00
●
0.00
●
0
●
0
●
0
●
0.0Hz
●
0
●
0
●
0.0
●
0
●
0
●
0.0Hz
●
0.0Hz
●
0
●
0
