Group P06—Output terminal functions
Function
Name
code
P06.00 HDO output type
P06.01 Y1 output selection 0: Invalid
HDO output
P06.02
selection
RO1 output
P06.03
selection
RO2 output
P06.04
selection
Description
0: Open collector high-speed pulse output. The
max. frequency of pulse is 50.00kHz. For
details about the related functions, see
P06.27–P06.31.
1: Open collector output. For details about the
related functions, see P06.02.
1: Running
2: Running forward
3: Running reversely
4: Jogging
5: VFD in fault
6: Frequency level detection FDT1
7: Frequency level detection FDT2
8: Frequency reached
9: Running in zero speed
10: Frequency upper limit reached
11: Frequency lower limit reached
12: Ready for running
13: Pre-exciting
14: Overload pre-alarm
15: Underload pre-alarm
16: Simple PLC stage completed
17: Simple PLC cycle completed
18: Set counting value reached
19: Designated counting value reached
20: External fault is valid
21: Reserved
22: Running time reached
23: Modbus/Modbus TCP communication
virtual terminal output (RO2/RO1/HDO/Y1)
24: PROFIBUS/CANopen/DeviceNet
communication virtual terminal output
(RO2/RO1/HDO/Y1)
25: Ethernet communication virtual terminal
output (RO2/RO1/HDO/Y1)
26: DC bus voltage established
27: Z pulse output
