INVT Goodrive350-19 Series Operation Manual page 176

Goodrive350-19 Series VFD for Crane
Function
Name
code
upper-limit
frequency in torque
control
Forward rotation
frequency upper
limit set through
P03.16
keypad in torque
control
Reverse rotation
upper-limit
frequency set
P03.17
through keypad in
torque control
Setting source of
electromotive
P03.18
torque upper limit
Setting source of
P03.19 braking torque
upper limit
Electromotive
P03.20 torque upper limit
set through keypad
Braking torque
P03.21 upper limit set
through keypad
P03.22 Weakening
Description
Used to set the frequency upper limits. 100%
corresponds to the max. frequency. P03.16
specifies the value when P03.14=1, while
P03.17 specifies the value when P03.15=1.
Setting range: 0.00Hz–P00.03 (Max. output
frequency)
0: Keypad (P03.20)
1: AI1
2: AI2
3: AI3
4: Pulse frequency HDIA
5: Modbus/Modbus TCP communication
6: PROFIBUS/CANopen/DeviceNet
communication
7: Ethernet communication
8: Pulse frequency HDIB
9: EtherCAT/PROFINET/EtherNet IP
communication
10: Programmable expansion card
11: Reserved
Note: For these settings, 100% corresponds
to the motor rated current.
0: Keypad (P03.21)
1–11: Same as those for P03.18
0.0–300.0% (of the motor rated current)
Note: It can be modified only when the ones
place of P11.26 = 1 indicating special
functions are enabled.
Used when the AM is in flux-weakening control.
-164-
Function parameters
Default Modify
○
50.00Hz
○
50.00Hz
○
0
○
0
○
250.0%
○
250.0%
○
0.8
