INVT Goodrive350-19 Series Operation Manual page 215

Goodrive350-19 Series VFD for Crane
Function
Name
code
Detection value for
P08.36 frequency being
reached
Enabling
P08.37 energy-consumptio
n braking
Energy-consumptio
P08.38 n braking threshold
voltage
Running mode of 0: The fan runs with the VFD; the fan stops 1
P08.39
Description
Setting range of P08.33: 0.0–100.0% (FDT1
electrical level)
Setting range of P08.34: 0.00Hz–P00.03 (Max.
output frequency)
Setting range of P08.35: 0.0–100.0% (FDT2
electrical level)
When the output frequency is within the
detection range, the multifunction digital output
terminal outputs the signal of "Frequency
reached".
Output frequency
Set
frequency
Y,
RO1, RO2
Setting range: 0.00Hz–P00.03 (Max. output
frequency)
0x00–0x11
Ones place:
0: Disable
1: Enable
Tens place:
0: Disable braking short-circuit protection
1: Enable braking short-circuit protection
Note: For the 380V models, the default value
is 0x11 for 11kW–110kW, 0x01 for <7.5kW,
and 0x00 for >110kW.
The function code is used to set the starting bus
voltage of energy consumption braking. Adjust
this value properly to achieve effective braking
for the load. The default value varies depending
on the voltage class.
Setting range: 200.0–2000.0V
-203-
Detection amplitude
Time t
Time t
Function parameters
Default Modify
○
0.00Hz
Model
○
depended
For 220V:
380.0V
For 380V:
○
700.0V
For 660V:
1120.0V
○
0
