Goodrive350-19 Series VFD for Crane
Function
Name
code
Power-off detection
P92.47
delay time
Power-loss
P92.48
recovery delay
Brake detection
P92.49 light-wear alarm
pulse threshold
Group P93—Closed-loop hoisting functions
Function
Name
code
Brake slip speed
P93.00
deviation
Braking slip fault
P93.01
delay time
Description
Output
frequency
Set frequency
Output
torque
Weight
P92.46
P92.45
A-OL
Alarm state
0.00–5.00s
If it is set to 0, the hundreds place of P92.00 is
invalid.
0.00–5.00s
0–20000
During manual or power-on brake detection,
when the detected pulse count is greater than
P92.49 (non zero) but less than P92.11, A-LbE
is reported; when the detected pulse count is
greater than P92.11, if P92.49 is not zero,
A-obE is reported, and if it is zero, bE is
reported.
Description
0.50–1.00Hz
Note: In FVC mode, when the detected
feedback frequency is greater than the
brake release frequency P93.00, which lasts
P93.01, it considers that the brake slip fault
bE occurs.
0.000–5.000s
The value 0 indicates brake slip is not detected,
while a non-zero value indicates brake slip is
-334-
Output
frequency
Set frequency
Output
torque
Weight
P92.46
P92.45
Fault state E-OvL
Function parameters
Default Modify
○
0.50s
○
0.30s
○
0
Default Modify
○
0.05Hz
○
0.500s
