Goodrive350-19 Series VFD for Crane
Function
Name
code
code of sent PZD11
Mapped function
P14.70 code of sent
PZD12
Group P15––Communication expansion card 1 functions
Function
Name
code
P15.01 Module address
P15.02 Received PZD2
P15.03 Received PZD3
P15.04 Received PZD4
P15.05 Received PZD5
P15.06 Received PZD6
P15.07 Received PZD7
P15.08 Received PZD8
P15.09 Received PZD9
P15.10 Received PZD10
P15.11 Received PZD11
P15.12 Received PZD12
Description
0x0000–0xFFFF
Description
0–127
0–49
0: Invalid
1: Set frequency (-Fmax–Fmax, unit: 0.01Hz)
2: PID reference (-1000–1000, in which 1000
corresponds to 100.0%)
3: PID feedback (-1000–1000, in which 1000
corresponds to 100.0%)
4: Torque setting (-3000–+3000, in which 1000
corresponds to 100.0% of the motor rated
current)
5: Setting of the upper limit of forward running
frequency (0–Fmax, unit: 0.01Hz)
6: Setting of the upper limit of reverse running
frequency (0–Fmax, unit: 0.01Hz)
7: Upper limit of the electromotive torque
(0–3000, in which 1000 corresponds to 100.0%
of the motor rated current)
8: Upper limit of braking torque (0–3000, in
which 1000 corresponds to 100% of the motor
rated current)
9: Virtual input terminal command. Range:
0x000–0x3FF
10: Virtual output terminal command (range:
0x00–0XFF, corresponding to
RO4/RO3/Y3/Y2/RO2/RO1/HDO/Y1)
11: Voltage setting (special for V/F separation)
(0–1000, in which 1000 corresponds to 100%
of the motor rated voltage)
12: AO1 output setting 1 (-1000–1000, in which
-236-
Function parameters
Default Modify
○
0x0000
Default Modify
◎
2
○
0
○
0
○
0
○
0
○
0
○
0
○
0
○
0
○
0
○
0
○
0
