INVT Goodrive350-19 Series Operation Manual page 297

Goodrive350-19 Series VFD for Crane
Function
Name
code
RO5 switch-off
P26.24
delay
RO6 switch-on
P26.25
delay
RO6 switch-off
P26.26
delay
RO7 switch-on
P26.27
delay
RO7 switch-off
P26.28
delay
RO8 switch-on
P26.29
delay
RO8 switch-off
P26.30
delay
RO9 switch-on
P26.31
delay
RO9 switch-off
P26.32
delay
RO10 switch-on
P26.33
delay
RO10 switch-off
P26.34
delay
AO2 output
P26.35
selection
P26.36 AO3 output selection
AO2 output lower
P26.38
limit
AO2 output
P26.39 corresponding to
lower limit
AO2 output upper
P26.40
limit
AO2 output
P26.41 corresponding to
upper limit
AO2 output filter
P26.42
time
AO3 output lower
P26.43
limit
Description
Same as the description for P06.14
The function codes define the relationship
between the output value and analog output.
When the output value exceeds the allowed
range, the output uses the lower limit or upper
limit.
When the analog output is current output, 1mA
equals 0.5V.
In different cases, the corresponding analog
output of 100% of the output value is different.
-285-
Function parameters
Default Modify
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0
○
0
○
0.0%
○
0.00V
○
100.0%
○
10.00V
○
0.000s
○
0.0%
