Goodrive350-19 Series VFD for Crane
Function
Name
code
value
REV light-load
speed-boost
P91.13
current detection
value
Description
success
Output
frequency
P00.10
Motor rated frequency
P91.10
Output
current
P91.12 or P91.13
No light load speed boost due to current
verification failure
If light load speed boost mode 1 is enabled,
processing for light load speed boost is
performed only when the set frequency is no
less than P02.02 (Motor rated frequency). After
running, if the ramp frequency is equal to or
greater than P91.10, current is detected and
count starts. When P91.11 is reached, if the
current is less than P91.12 (or P91.13 in
reverse running), the current detection passes,
the VFD increases the frequency to P91.09. If
the current detection fails, the VFD remains the
original frequency.
Note:
The
light-load
frequency setting must be higher than the set
frequency. Otherwise, speed boost cannot be
implemented although the conditions are met. If
the set frequency is higher than P91.10, the
original frequency is remained.
Setting range of P91.09: 0.00–100.00Hz
P91.10 setting range: 50.0%–100.0% (of the
motor rated frequency)
Setting range of P91.11: 0.0–10.000s
Setting
range
of
0.0–150.0%
-314-
No light load speed
boost due to current
verification failure
P91.11
Time
No light load speed
boost due to current
verification failure
speed-boost
P91.12
and
P91.13:
Function parameters
Default Modify
Time
40.0 %
