Goodrive350-19 Series VFD for Crane
Function
Name
code
Enabling special
P11.26
functions
Description
Overload time
60min
30min
10min
5min
60s
45s
30s
15s
6s
3s
1s
114% 123% 132% 141% 150%
Overload start 1
Start/stop command
Overload counting
P11.25=0
When
P17.48
Overload counting
When P11.25=1
P17.48
Ones place: Special function 1
0: Disable
1: Enable
Tens place: Special function 2
0: Disable
1: Enable
Hundreds place: Special function 3
0: Disable
1: Enable
Special functions 1 include P11.03 (Overvoltage
stall protection),
selection), P01.00 (Running mode of start),
P00.13 (Running direction), P03.20 (Set upper
limit of the torque when motoring via keypad),
P03.21 (Set upper limit of brake torque via
keypad), and
energy-consumption braking.
When this parameter is set to 0, special
function codes (except P08.37) are restored to
the factory settings and are not displayed, and
-223-
VFD rated
current %
159% 168% 177% 186% 195% 204%
Overload end 1 Overload start 2
Start Start
Time t
Time t
P11.05 (Current-limit
P08.37Enabling
Function parameters
Default Modify
◎
0x000
Time t
