Goodrive350-19 Series VFD for Crane
VFD model
GD350-19-400G-4
GD350-19-450G-4
GD350-19-500G-4
Note:
The input current of the 1.5–500kW VFD models is measured in cases where the input voltage is
380V without additional reactors.
The rated output current is the output current when the output voltage is 380V.
Within the allowable input voltage range, the output current/power cannot exceed the rated
output current/power.
VFD model
GD350-19-022G-6
GD350-19-030G-6
GD350-19-037G-6
GD350-19-045G-6
GD350-19-055G-6
GD350-19-075G-6
GD350-19-090G-6
GD350-19-110G-6
GD350-19-132G-6
GD350-19-160G-6
GD350-19-185G-6
GD350-19-200G-6
GD350-19-220G-6
GD350-19-250G-6
GD350-19-280G-6
GD350-19-315G-6
GD350-19-355G-6
GD350-19-400G-6
GD350-19-450G-6
GD350-19-500G-6
GD350-19-560G-6
GD350-19-630G-6
Note:
Output power (kW)
400
450
500
Table 3-4 AC 3PH 520V(-15%) – 690V(+10%)
Output power (kW)
22
30
37
45
55
75
90
110
132
160
185
200
220
250
280
315
355
400
450
500
560
630
Input current (A)
715
840
890
Input current (A)
35
40
47
52
65
85
95
118
145
165
190
210
230
255
286
334
360
411
445
518
578
655
-19-
Product overview
Output current (A)
720
820
860
Output current (A)
27
35
45
52
62
86
98
120
150
175
200
220
240
270
300
350
380
430
465
540
600
680
