P17.24 PID feedback value
P17.25 Motor power factor
P17.26 Duration of this run
Simple PLC and
P17.27 actual step of
multi-step speed
Motor ASR
P17.28
controller output
Open-loop SM pole
P17.29
angle
Phase
P17.30 compensation of
SM
High-frequency
P17.31 superposition
current of SM
P17.32 Motor flux linkage 0.0%–200.0%
Exciting current
P17.33
reference
Torque current
P17.34
reference
AC incoming
P17.35
current
P17.36 Output torque
Description
Displays the PID feedback value.
Range: -100.0–100.0%
Displays the power factor of the present motor.
Range: -1.00–1.00
Displays the duration of this run of the VFD.
Range: 0–65535min
Displays simple PLC and present step number
of multi-step speed.
Range: 0–15
Displays the ASR controller output value under
the vector control mode, relative to the
percentage of rated motor torque.
Range: -300.0%–300.0% (of the motor rated
current)
Displays the initial identification angle of SM.
Range: 0.0–360.0
Displays the phase compensation of SM.
Range: -180.0–180.0
0.0%–200.0% (of the motor rated current)
Displays the exciting current reference value
under the vector control mode.
Range: -3000.0–3000.0A
Displays the torque current reference value
under the vector control mode.
Range: -3000.0–3000.0A
Displays the valid value of incoming current on
AC side.
Range: 0.0–5000.0A
Display output torque.
During forward running, a positive value
indicates it is in the motoring state while a
negative value indicates it is in the generating
state.
During reverse running, a positive value
-252-
Function parameters
Default Modify
●
0.0%
●
1.00
●
0m
●
0
●
0.0%
●
0.0
●
0.0
●
0.0
●
0.0%
●
0.0A
●
0.0A
●
0.0A
●
0.0Nm
