6.4.3 Viewing VFD status
The VFD provides group P17 for status viewing. You can enter group P17 for viewing.
All digits are blinking.
The units place is blinking.
Note: When setting the value, you can press
6.5 Basic operation description
6.5.1 What this section describes
This section introduces the function modules inside the VFD.
 Ensure that all terminals have been securely connected.
 Ensure that the motor power matches the VFD power.
6.5.2 Common commissioning procedure
6.5.3 Vector control
6.5.4 Space voltage vector control mode
6.5.5 Torque control
6.5.6 Motor parameters
6.5.7 Start/stop control
6.5.8 Frequency setting
6.5.9 Analog input
6.5.10 Analog output
6.5.11 Digital input
6.5.12 Digital output
6.5.13 Simple PLC
For details about sections 6.5.2 Common commissioning procedure to 6.5.13 Simple PLC, see the
Goodrive350 Series High-performance Multifunction VFD Operation Manual.
PRG
ESC
PRG
ESC
The units place is blinking.
DATA
ENT
The units place is blinking. The units place is blinking.
Figure 6-5 Viewing a parameter
