INVT Goodrive300-01A Series Operation Manual
  1. Manuals
  2. Brands
  3. INVT Manuals
  4. DC Drives
  5. Goodrive300-01A Series
  6. Operation manual

INVT Goodrive300-01A Series Operation Manual

Vdf for air compressor
Hide thumbs Also See for Goodrive300-01A Series:
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Goodrive300-01A Series and is the answer not in the manual?

Questions and answers

Related Manuals for INVT Goodrive300-01A Series

Summary of Contents for INVT Goodrive300-01A Series

  • Page 2 Goodrive300-01A series VFD for air compressor Preface Preface Goodrive300-01A series variable-frequency drive (VFD) for air compressors (hereinafter referred to as GD300-01A VFD) is designed and optimized based on Goodrive300-01 to be applied in synchronous/asynchronous air compressor for optimal control performance.
  • Page 3 Goodrive300-01A series VFD for air compressor Contents Contents Preface ................................. i Contents ..............................ii Chapter 1 Safety precautions ........................1 1.1 Contents of this chapter ......................1 1.2 Definition of safety information ....................1 1.3 Warning symbols ........................1 1.4 Safety instruction ........................2 1.4.1 Shipment and installation ......................
  • Page 4 Goodrive300-01A series VFD for air compressor Contents 5.3.2 PID adjusting methods ......................85 5.4 Operating logic of blower oil pump ..................89 Chapter 6 Fault information and troubleshooting ................90 6.1 VFD faults and solutions ......................90 6.2 Fault contents and solutions of air compressor equipment ............. 95 Appendix A Product dimension ......................
  • Page 5 Goodrive300-01A series VFD for air compressor Contents C.1 Current transformer model selections .................. 157 C.2 Wiring of current transformer of the fan ................157 C.3 Parameter setup of current transformer of the fan ............... 158 Appendix D Communication protocol ....................159 D.1 Application mode .........................
  • Page 6 Goodrive300-01A series VFD for air compressor Safety precautions Chapter 1 Safety precautions 1.1 Contents of this chapter Read this manual carefully and follow all safety precautions before moving, installing, operating and servicing the VFD. Should the safety precautions be ignored, physical injury or death may occur, or damage may occur to the devices.
  • Page 7 Installation site must be away from children and other public places.  When the altitude exceeds 1000m, derate by 1% for every increase of 100m. When the altitude exceeds 3000m, consult the local INVT dealer or office for details.  The application environment should be proper and appropriate.
  • Page 8 Goodrive300-01A series VFD for air compressor Safety precautions techniques and ensure the grounding resistor is less than 10Ω. The conductivity of PE grounding conductor is the same as that of the phase conductor (with the same cross sectional area). For models of higher than 30 kW, the cross sectional area of the PE grounding conductor can be slightly less than the recommended area.
  • Page 9 Goodrive300-01A series VFD for air compressor Safety precautions 1.4.4 Scrap treatment  There are heavy metals in the VFD. Treat with it as industrial effluent.  When the life cycle ends, the product should enter the recycling system. Dispose of it separately at an appropriate collection point instead of placing it in...
  • Page 10 Goodrive300-01A series VFD for air compressor Product overview Chapter 2 Product overview 2.1 Product specification Category Function Specification 3PH 380V (-15%)–440V (+10%) Input voltage of the VFD (V) 3PH 220V (-15%)–240V (+10%) Rated input current (A) Refer to 2.4 "Rated specifications".
  • Page 11 Goodrive300-01A series VFD for air compressor Product overview Category Function Specification Two relay outputs (NO) 250VAC/3A; one Digital output convertible relay output 250VAC/3A Over 30 kinds of fault protection functions: overcurrent, overvoltage, undervoltage, Fault protection function overtemperature, phase loss, overload, fan current imbalance, etc.
  • Page 12 Goodrive300-01A series VFD for air compressor Product overview Category Function Specification models and can be externally connected. C3 filters have been built into the VFDs as standard configuration. ECM filter is set to be invalid by default, if it is necessary to enable it, users can connect J10 (see 3.1.3 and 3.1.4 for...
  • Page 13 Goodrive300-01A series VFD for air compressor Product overview Sign Description Content 2: AC 3PH 220V(-15%)–240V(+10%) ○ Voltage class 4: AC 3PH 380V(-15%)–440V(+10%) Empty: VFD dedicated for single-VFD air compressor Single-VFD air compressor integrated machine Power-frequency fan/ C: Built-in contactor unit, supporting power-frequency fan ○...
  • Page 14 Goodrive300-01A series VFD for air compressor Product overview Output power Input current Output current Installation dimension Product model (kW) description Same as GD300-01A-132G-2 GD300-01A-250G-4 Same as GD300-01A-160G-2 GD300-01A-280G-4 Same as GD300-01A-185G-2 GD300-01A-315G-4 AC 3PH 380V(-15%)–440V(+10%) Product model Output power (kW)
  • Page 15 Goodrive300-01A series VFD for air compressor Product overview 2.4.2 Rated value of single-VFD integrated machine Frequency conversion of Power frequency of the Rated input main motor current of the Model Rated Rated Rated integrated Rated output output output output machine (A)
  • Page 16 Goodrive300-01A series VFD for air compressor Wiring instruction Chapter 3 Wiring instruction 3.1 Main circuit wiring and terminal description 3.1.1 Main circuit wiring diagram of single VFD Figure 3-1 7.5kW main circuit wiring diagram Note: There is brake circuit but no DC reactor for 7.5kW Figure 3-2 11–15kW main circuit wiring diagram...
  • Page 17 Goodrive300-01A series VFD for air compressor Wiring instruction Figure 3-4 132–315kW main circuit wiring diagram Note:  DC reactors are optional parts for 132–315kW VFD models and can be externally connected.  See Appendix B for filter and reactor model selection.
  • Page 18 Goodrive300-01A series VFD for air compressor Wiring instruction 3.1.3 Main circuit terminal diagram of single VFD Figure 3-6 7.5kW main circuit terminal diagram Figure 3-7 11–15kW main circuit terminal diagram Figure 3-8 18.5–22kW main circuit terminal diagram -13-...
  • Page 19 Goodrive300-01A series VFD for air compressor Wiring instruction Figure 3-9 30–37kW main circuit terminal diagram Figure 3-10 45–55kW main circuit terminal diagram Figure 3-11 75kW main circuit terminal diagram -14-...
  • Page 20 Goodrive300-01A series VFD for air compressor Wiring instruction Figure 3-12 90–110kW main circuit terminal diagram Figure 3-13 132–200kW main circuit terminal diagram -15-...
  • Page 21 Goodrive300-01A series VFD for air compressor Wiring instruction A1 A2 POWER MOTOR Figure 3-14 220–315kW main circuit terminal diagram Table 3-1 Screw specification and torque of main circuit terminals of a single VFD · Power range (kW) Terminal screw specification Torque of torque driver (N 7.5–15...
  • Page 22 Goodrive300-01A series VFD for air compressor Wiring instruction 3.1.4 Main circuit terminal diagram of single-VFD integrated machine Figure 3-15 Main circuit terminal diagram of 7.5–15kW single-VFD integrated machine Table 3-3 Screw specification and torque of main circuit terminals of 7.5kW–15kW single-VFD integrated machine ·...
  • Page 23 Goodrive300-01A series VFD for air compressor Wiring instruction 3.2 Control circuit wiring and terminal description GD300-01A series Emergency-stop to current transformer Fan fault User-defined +24V User-defined to power detection module CN10 485+ User-defined 485- +24V +24V to wireless data collection...
  • Page 24 Goodrive300-01A series VFD for air compressor Wiring instruction Category Sign Name Function PTA1 Analog temperature 1. Resolution rate: 1° C signal 1 PTB1 PT100 signal 2. Range: -20° C–150° C input PTA2 Analog temperature 3. Detection precision: 3° C PTB2...
  • Page 25 Goodrive300-01A series VFD for air compressor Wiring instruction Category Sign Name Function 3. Input impedance: 50Ω B-phase current input of the fan Note: See Appendix C for model selection of current transformer. C-phase current input of the fan I corresponds to current signal, V...
  • Page 26 Goodrive300-01A series VFD for air compressor Wiring instruction • • • • +24V +24V +24V +24V ● ● • • +24V ● ● ● ● Figure 3-19 Internal power (NPN mode) Figure 3-20 External power (PNP mode) When the digital input uses internal +24V, set J9 according to Figure 3-19, and short +24V to PW.
  • Page 27 It is recommended to use TC070A touch screen for display and commissioning. Note:  If you use a controller from another manufacturer, contact INVT technical support.  All the parameters displayed in the interfaces and are subject to actual displayed content.
  • Page 28 Goodrive300-01A series VFD for air compressor Commissioning instruction Figure 4-2 Login interface 3. Click Enter IN to enter the working environment interface, as shown in Figure 4-3. Figure 4-3 Working interface 4. Click Menu on the interface. The interface shown in Figure 4-4 is displayed.
  • Page 29 Goodrive300-01A series VFD for air compressor Commissioning instruction 5. Click System config on the touch screen to enter the system configuration interface, as shown in Figure 4-5. Figure 4-5 System configuration interface Click Able for the fan VFD, and perform commissioning according to the commissioning guide.
  • Page 30 Goodrive300-01A series VFD for air compressor Commissioning instruction Figure 4-6 Main motor parameter setting interface Set motor parameters according to the actual motor nameplate parameters, click Para autotune, and then click Next. On the interface shown, set fan motor parameters (including the max frequency, rated frequency, rated power, rated voltage, rated current, and rated rotational speed).
  • Page 31 Goodrive300-01A series VFD for air compressor Commissioning instruction Function code Parameter setting Description 2: V/F control Select the mode according to the motor type. P00.01 2: Communication P00.06 Set via PID control P01.15 35.00 Stop frequency: 35Hz P03.27 Display as per the set value Pressure setting of dedicated function of air P09.00...
  • Page 32 Goodrive300-01A series VFD for air compressor Commissioning instruction Step 4 On the system configuration interface, click Debug Mode. The interface shown in Figure 4-9 is displayed. Figure 4-9 Debug mode interface Click Jog for the main motor to determine the motor rotation direction; click Load or Unload to test the action of solenoid valve.
  • Page 33 Goodrive300-01A series VFD for air compressor Commissioning instruction 7. Choose Maintenance parameter in the menu. The interface shown in Figure 4-11 is displayed. Figure 4-11 Maintenance parameter interface 8. Choose Protect parameter in the menu. The interface shown in Figure 4-12 is displayed.
  • Page 34 Goodrive300-01A series VFD for air compressor Commissioning instruction Figure 4-13 Running information interface 10. After adjusting user parameters, factory parameters and maintenance parameters according to the manual, return to Workspace interface and click Start to run. 4.2 Commissioning guidance for single-VFD air compressor 4.2.1 Wiring diagram for single-VFD air compressor system...
  • Page 35 Goodrive300-01A series VFD for air compressor Commissioning instruction Note: Pay attention to the terminals with the same name when installing and wiring the current transformer. For details, see Appendix C "Current transformer of the fan" for precautions. 4.2.2 Commissioning steps for single-VFD air compressor 1.
  • Page 36 Goodrive300-01A series VFD for air compressor Commissioning instruction 4.3 Commissioning guidance for dual-VFD + power-frequency fan scheme Master VF D GD300-01A-RT Emergency stop GD 300-0 1A Sole no id v alv e c oil RO2A S ta r t/s to p s ig n a l...
  • Page 37 Goodrive300-01A series VFD for air compressor Commissioning instruction Function Parameter Name Remarks code setting S1 terminal P05.01 1: Forward running function selection S2 terminal P05.02 49: Solenoid valve control signal function selection S3 terminal P05.03 50: Cooling fan control signal of main motor...
  • Page 38 Note:  RO1 port of single-VFD integrated machine is connected to solenoid valve coil port by default before delivery. If the touch screen used are made by other manufactures other than INVT, please set RO1 to solenoid valve control (P06.03=28).
  • Page 39 Goodrive300-01A series VFD for air compressor Function code description Chapter 5 Function code description 5.1 Function codes “○” indicates the parameter value can be modified during stop and running; “◎” indicates the parameter value cannot be modified when the VFD is running;...
  • Page 40 Goodrive300-01A series VFD for air compressor Function code description Function Name Description Default Modify code 5: Reserved 6: Set via multi-step speed running 7: Set via PID control 8: Set via Modbus communication 9–11: Reserved Reference object of B 0: Max. output frequency ○...
  • Page 41 Goodrive300-01A series VFD for air compressor Function code description Function Name Description Default Modify code Plot controller) 4: Start/stop the VFD with one click in terminal mode (compatible with the Plot controller) 5–6: Reserved 7: Customer 1 parameter 1 8: Customer 1 parameter 2...
  • Page 42 Goodrive300-01A series VFD for air compressor Function code description Function Name Description Default Modify code Depend ◎ P02.03 Rated speed of AM 1 1–36000rpm on model Depend ◎ P02.04 Rated voltage of AM 1 0–1200V on model Depend ◎ P02.05 Rated current of AM 1 0.8–6000.0A...
  • Page 43 Goodrive300-01A series VFD for air compressor Function code description Function Name Description Default Modify code Quadrature-axis Depend ○ P02.22 0.01–655.35mH inductance of SM 1 on model Counter-emf constant ○ P02.23 0–10000 of SM 1 0: No protection Normal motor (with...
  • Page 44 Goodrive300-01A series VFD for air compressor Function code description P03 group Vector control Function Name Description Default Modify code ASR proportional gain ○ P03.00 0–200.0 20.0 ○ P03.01 ASR integral time 1 0.000–10.000s 0.200s Switching low point ○ P03.02 0.00Hz–P03.05 5.00Hz...
  • Page 45 Goodrive300-01A series VFD for air compressor Function code description Function Name Description Default Modify code Keypad setting of the ○ P03.21 upper limit of brake 0.0–300.0% (rated motor current) 180.0% torque Flux-weakening ○ P03.22 coefficient in constant 0.1–2.0 power area Min.
  • Page 46 Goodrive300-01A series VFD for air compressor Function code description Function Name Description Default Modify code of motor 1 /P04.05–P02.16 (rated frequency of motor 1) V/F voltage point 3 of ○ P04.08 0.0%–110.0% (rated voltage of motor 1) 00.0% motor 1 V/F slip compensation ○...
  • Page 47 Goodrive300-01A series VFD for air compressor Function code description Function Name Description Default Modify code S4 terminal function 6: Coast to stop ◎ P05.04 selection 7: Fault reset 8: Running pause S5 terminal function ◎ P05.05 9: External fault input selection 10–24: Reserved...
  • Page 48 Goodrive300-01A series VFD for air compressor Function code description Function Name Description Default Modify code S2 terminal switch-off ○ P05.17 0.000–50.000s 0.000s delay S3 terminal switch-on ○ P05.18 0.000–50.000s 0.000s delay S3 terminal switch-off ○ P05.19 0.000–50.000s 0.000s delay S4 terminal switch-on ○...
  • Page 49 Goodrive300-01A series VFD for air compressor Function code description Function Name Description Default Modify code corresponding to input voltage can be obtained by the linear relationship between upper lower limits their corresponding settings. Present temperature corresponding percentage × 160℃ Note: Though restoring to default values is enabled, P05.38, P05.40, P05.48, and P05.50...
  • Page 50 Goodrive300-01A series VFD for air compressor Function code description P06 group Output terminals Function Name Description Default Modify code ○ P06.01 Reserved 0: Invalid ○ 1: In running P06.02 RO3 output selection 2: In forward running ○ P06.03 RO1 output selection...
  • Page 51 Goodrive300-01A series VFD for air compressor Function code description Function Name Description Default Modify code 2: Ramps reference frequency 3: Running speed (relative to two times the motor synchronous rotation speed) 4: Output current (relative to two times the rated current of the VFD)
  • Page 52 Goodrive300-01A series VFD for air compressor Function code description P07 group HMI Function Name Description Default Modify code ○ P07.00 User password 0–65535 0: No operation 1: Uploading function parameters from the machine to keypad 2: Downloading function parameters (including the motor parameters) from the...
  • Page 53 Goodrive300-01A series VFD for air compressor Function code description Function Name Description Default Modify code High bit of power ● P07.15 consumption of the 0–65535 kWh (*1000) Low bit of power ● P07.16 consumption of the 0.0–999.9 kWh 0: G type ●...
  • Page 54 Goodrive300-01A series VFD for air compressor Function code description Function Name Description Default Modify code 21: EEPROM operation fault (EEP) 22: PID feedback offline fault (PIDE) 23: Reserved 24: Running time reached (END) 25: Electronic overload (OL3) 26: Panel communication error (PCE)
  • Page 55 Goodrive300-01A series VFD for air compressor Function code description Function Name Description Default Modify code Output terminal status ● P07.40 at present fault Running frequency at ● P07.41 0.00 last fault Ramp reference ● P07.42 0.00 frequency at last fault Output voltage at last ●...
  • Page 56 Goodrive300-01A series VFD for air compressor Function code description P08 group Enhanced functions Function Name Description Default Modify code 0–0x11Ones: Bus protection function Bus voltage ○ P08.15 Tens: Low-frequency current protection 0x10 pre-protection function function Low-voltage protection ○ P08.16 0.0V–2000.0V 300.0V...
  • Page 57 Goodrive300-01A series VFD for air compressor Function code description Function Name Description Default Modify code used in the calculation. 1: Enable It is applicable to the embedded/ surface-mounted synchronous motors. P02.21 (Direct-axis inductance of SM 1) is used in the calculation.
  • Page 58 Goodrive300-01A series VFD for air compressor Function code description Function Name Description Default Modify code IGBT temperature is higher than 50℃ and turns off when it is lower than 45℃. 0x00–0x21 LED ones: PWM mode selection 0: PWM mode 1, 3PH modulation and 2PH...
  • Page 59 Goodrive300-01A series VFD for air compressor Function code description Function Name Description Default Modify code potentiometer integral function 0: The integral function is valid 1: The integral function is invalid Integral time of digital ○ P08.43 0.01–10.00s 0.10s potentiometer 0x00–0x221...
  • Page 60 Goodrive300-01A series VFD for air compressor Function code description Function Name Description Default Modify code 1: Clear the setting at power-off. High bit of initial value ○ P08.48 0–59999° (k) 0° of power consumption Low bit of initial value ○...
  • Page 61 Goodrive300-01A series VFD for air compressor Function code description Function Name Description Default Modify code feedback signal is larger than PID reference, which requires the VFD output frequency to increase to balance PID, e.g. tension PID control of unwinding. It determines the regulation intensity of the whole PID regulator, the larger the P is, the stronger the regulation intensity is.
  • Page 62 Goodrive300-01A series VFD for air compressor Function code description Function Name Description Default Modify code Setting range: 0.00–10.00s It means the sampling cycle of feedback quantity. The regulator calculates once during ○ P09.07 Sampling cycle (T) each sampling cycle. The longer the sampling 0.100s...
  • Page 63 Goodrive300-01A series VFD for air compressor Function code description Function Name Description Default Modify code 1: Enable input phase loss software protection Note: LED ones place detects input phase loss by phase sequence detection circuit. LED tens: 0: Disable output phase loss protection...
  • Page 64 Goodrive300-01A series VFD for air compressor Function code description Function Name Description Default Modify code 0x000–0x131 LED ones: Motor overload/underload pre-alarm, relative to the motor rated current, 1: VFD overload/underload pre-alarm, relative to the VFD rated current LED tens: 0: The VFD keeps running after reporting an overload/underload alarm.
  • Page 65 Goodrive300-01A series VFD for air compressor Function code description P13 group SM control Function Name Description Default Modify code Pull-in current ○ P13.00 0.0–100.0% 50.0% reduction coefficient 0: Do not detection Initial magnetic pole ◎ P13.01 1: High frequency superposition (reserved)
  • Page 66 Goodrive300-01A series VFD for air compressor Function code description Function Name Description Default Modify code 0: No parity check (N, 8, 1) for RTU 1: Even parity (E, 8, 1) for RTU 2: Odd parity (O, 8, 1) for RTU ○...
  • Page 67 Goodrive300-01A series VFD for air compressor Function code description Function Name Description Default Modify code 0.00–20.00MPa Auxiliary pressure The VFD cannot start if present auxiliary ○ P15.01 start protection 0.30MPa pressure (P19.20) is greater than auxiliary threshold pressure start protection threshold (P15.01).
  • Page 68 Goodrive300-01A series VFD for air compressor Function code description Function Name Description Default Modify code 0.00–20.00MPa When the auxiliary pressure protection is enabled (P18.39=1), if the auxiliary pressure is Auxiliary pressure less than the value set in P15.07, the auxiliary ○...
  • Page 69 Goodrive300-01A series VFD for air compressor Function code description Function Name Description Default Modify code -300.0%–300.0% (relative to rated motor ● P17.08 Motor power 0.0% power) ● P17.09 Output torque -250.0–250.0% 0.0% Estimated motor ● P17.10 0.00–P00.03 0.00Hz frequency ●...
  • Page 70 Goodrive300-01A series VFD for air compressor Function code description Function Name Description Default Modify code Display analog input voltage value of PT2 channel. Under air-compressor mode, connect PT100 thermal resistor temperature sensor, different temperature generates corresponding resistor value, and different...
  • Page 71 Goodrive300-01A series VFD for air compressor Function code description Function Name Description Default Modify code Motor overload count 0–100 (OL1 fault is reported when the count ● P17.37 value value reaches 100) Display the output value of PID control of discharge pressure signal;...
  • Page 72 Goodrive300-01A series VFD for air compressor Function code description Function Name Description Default Modify code 0: Invalid 1: Automatic sleep mode 2: Manual sleep mode Note: When automatic sleep function is valid and unloading conditions are fulfilled, the VFD decelerates to P18.12...
  • Page 73 Goodrive300-01A series VFD for air compressor Function code description Function Name Description Default Modify code ○ P18.06 Loading pressure when air compressor control is valid and the 0.60Mpa air compressor supplies air as normal, if the discharge pressure is higher than P18.05, unloading automatically.
  • Page 74 Goodrive300-01A series VFD for air compressor Function code description Function Name Description Default Modify code P01.15–P18.11 (lower-limit frequency No-load running load-carrying running) ○ P18.12 38.00 Hz frequency The output working frequency allowed during no-load of air compressor. When sleep function is valid, after unloading, the VFD runs at no-load frequency in the time set by P18.13, and then enters sleep state.
  • Page 75 Goodrive300-01A series VFD for air compressor Function code description Function Name Description Default Modify code to 1, and emergency-stop will be applied. When machine head temperature is lower than P18.21, system indicates low-temperature pre-alarm by setting BIT14 of P19.13 to 1, and air compressor cannot start.
  • Page 76 Goodrive300-01A series VFD for air compressor Function code description Function Name Description Default Modify code P18.29. Setting range: 0.00–10.00V Note: This value will stay in currently set value when restoring to default values. 0.00–P18.04 When current pressure is larger than this Pressure drop value of ○...
  • Page 77 Goodrive300-01A series VFD for air compressor Function code description Function Name Description Default Modify code by setting BIT10 of P19.14 to 1, and emergency-stop will be applied. 0: Discharge pressure P1, auxiliary pressure 1: Discharge pressure P2, auxiliary pressure Pressure sensor ◎...
  • Page 78 Goodrive300-01A series VFD for air compressor Function code description Function Name Description Default Modify code 0–120% Add automatic frequency reduction function. When the output current is larger than Automatic frequency automatic frequency reduction threshold, it ○ P18.44 120% reduction threshold...
  • Page 79 Goodrive300-01A series VFD for air compressor Function code description Function Name Description Default Modify code Display motor output power, it can be Actual output power of ● P19.10 calibrated by P18.22. 0.0kW the motor Range: 0.0–6553.5kW Display discharge pressure value detected currently.
  • Page 80 Goodrive300-01A series VFD for air compressor Function code description Function Name Description Default Modify code 1: Fault; 0: Normal BIT2: Separator blockage signal 1: Fault; 0: Normal BIT3: Precision splitter blockage signal 1: Fault; 0: Normal BIT4: External fault signal 1 1: Fault;...
  • Page 81 Goodrive300-01A series VFD for air compressor Function code description Function Name Description Default Modify code 1: Maintenance required; 0: Normal BIT5: Auxiliary pressure signal 1: Auxiliary pressure signal fault; 0: Normal BIT6: Auxiliary temperature signal 1: Auxiliary temperature signal fault; 0: Normal BIT7: Auxiliary pressure pre-alarm signal 1: Pressure pre-alarm;...
  • Page 82 Goodrive300-01A series VFD for air compressor Function code description Function Name Description Default Modify code Display the output value of temperature PID regulation machine head, 100% Output value of ● P19.19 corresponds to P00.03 [the max. output 0.00% temperature PID frequency of the fan].
  • Page 83 Goodrive300-01A series VFD for air compressor Function code description Function Name Description Default Modify code If the VFD enables phase sequence detection and input phase loss hardware protection, corresponding fault will be reported when negative sequence and any phase loss Input power phase occurs;...
  • Page 84 Goodrive300-01A series VFD for air compressor Function code description Function Name Description Default Modify code Calibration coefficient ○ P21.06 of C phase current of 100.0% the fan Ones: Motor overload (OL1) 0: Coast to stop 1: Runs at alternative frequency of P21.10 Tens: Electronic overload (OL3) 0: Process as per P11.08...
  • Page 85 Goodrive300-01A series VFD for air compressor Function code description Function Name Description Default Modify code power-frequency fan (SPOF) 0: Coast to stop 1: Run at alternative frequency of P21.10 ○ P21.10 Alternative frequency 0.0–100.0% (max. output frequency) 50.0% 0.0–6000.0s Note: When user-defined fault occurs to the...
  • Page 86 Goodrive300-01A series VFD for air compressor Function code description 5.2 Control logic of the air compressor (1) The following figure shows the control logic of the air compressor. Standby Start command Restart delay P18.16 reached No-load running Stop delay P18.14...
  • Page 87 Goodrive300-01A series VFD for air compressor Function code description (2) The following figure shows the pressure and running frequency control during the running of the air compressor. Present pressure P18.05 P18.07 P18.06 Time Loading valve Present running frequency P00.04 P18.11 P18.12...

  • Page 88: Table Of Contents

    Goodrive300-01A series VFD for air compressor Function code description compressor enters normal air supply state after starts. When the discharge pressure is higher than P18.05, automatic unloading will be applied, and the VFD enters sleep state. If sleep function is invalid, the VFD will continue running at no-load frequency P18.12.
  • Page 89 Goodrive300-01A series VFD for air compressor Function code description in oscillation. To solve this problem, first, set the integral time to a large value and the derivative time to 0, and run the system by proportional control, and then change the reference to observe the deviation between feedback signal and the reference (static difference), if the static difference is (e.g.,...
  • Page 90 Goodrive300-01A series VFD for air compressor Function code description d. Empty system load, perform load-carrying joint debugging, and then fine-tune PID parameter until fulfilling the requirement. 5.3.2 PID adjusting methods After setting the parameters controlled by PID, you can adjust these parameters by the following means.

  • Page 91: Keypad (Pid Reference Source)

    Goodrive300-01A series VFD for air compressor Function code description control vibration. When derivative time (Td) is set to 0.00 (namely no derivative control), and there is no way to control vibration, decrease the proportional gain. After adjustment Response Before adjustment...
  • Page 92 Goodrive300-01A series VFD for air compressor Function code description Function Name Description Default code 1: PID output characteristic is negative: feedback signal is larger than PID reference, which requires the VFD output frequency to increase to balance PID, e.g. tension PID control of unwinding.

  • Page 93: Pid Stops

    Goodrive300-01A series VFD for air compressor Function code description Function Name Description Default code sampling cycle. The longer the sampling cycle, the slower the response speed. Setting range: 0.001–10.000s It means the max. allowed deviation quantity of the PID system feedback value relative to closed-loop reference value.
  • Page 94 Goodrive300-01A series VFD for air compressor Function code description 5.4 Operating logic of blower oil pump Dedicated function of the blower oil pump: RO terminal is enabled after the VFD start command is received, the VFD starts after start delay time (P01.23) is reached and stops after the VFD stop command is received.
  • Page 95 Goodrive300-01A series VFD for air compressor Fault information and troubleshooting Chapter 6 Fault information and troubleshooting 6.1 VFD faults and solutions Note: The numbers enclosed in square brackets such as [1], [2] and [3] in the Fault type column in the following table indicate the VFD fault type codes read through communication.
  • Page 96 Goodrive300-01A series VFD for air compressor Fault information and troubleshooting Fault Fault type Possible cause Solution code transients  Increase acceleration time.  Acceleration is too fast.  Restart the motor after stop.  The motor is restarted  Check grid voltage.

  • Page 97: Pid Feedback Source

    Goodrive300-01A series VFD for air compressor Fault information and troubleshooting Fault Fault type Possible cause Solution code  Motor parameters are set nameplate parameters improperly. correctly.   The deviation between the Empty the motor load and parameters obtained from identify again.
  • Page 98 Goodrive300-01A series VFD for air compressor Fault information and troubleshooting Fault Fault type Possible cause Solution code  Check the environment and  Keypad line is poorly rule out the interference contacted or disconnected. source.  [28] Parameter Keypad wire is too long or ...
  • Page 99 Goodrive300-01A series VFD for air compressor Fault information and troubleshooting Fault Fault type Possible cause Solution code  Increase the set value of P21.03 properly to lower down the sensitivity during determining imbalance degree.  Check whether the set value of P21.00 is the same with the rated current of the fan nameplate.
  • Page 100 Goodrive300-01A series VFD for air compressor Fault information and troubleshooting 6.2 Fault contents and solutions of air compressor equipment Abnormal state and solutions of air compressor equipment: P19.13 State type Possible cause Solution   BIT0=1 Air filter blocked Air filter is abnormal.
  • Page 101 Goodrive300-01A series VFD for air compressor Fault information and troubleshooting P19.13 State type Possible cause Solution not select current signal.  Check whether the wiring of PT100 is normal.   Temperature signal PT100 sensor is Check whether temperature BIT13=1 fault disconnected.

  • Page 102: Value

    Goodrive300-01A series VFD for air compressor Fault information and troubleshooting P19.14 State type Possible cause Solution  Temperature detection sensor is abnormal.  Temperature detection input circuit is abnormal.  Pressure detection sensor is  The actual voltage abnormal. Auxiliary pressure detected by P2 is larger ...
  • Page 103 Goodrive300-01A series VFD for air compressor Fault information and troubleshooting P19.14 State type Possible cause Solution  Any part whose running time exceeds the set value will enter overtime maintenance  Maintenance timeout stage, and hereafter, if Carry out maintenance on the...
  • Page 104 Goodrive300-01A series VFD for air compressor Product dimension Appendix A Product dimension A.1 Keypad diagram Function indicator Digital display area Unit indicator Digital potentiometer Increase/decrease key Program/exit key Confirmation key Short-cut multi-function key Right shift key Run key Stop/fault reset key A.2 External keypad installation dimensions...
  • Page 105 Goodrive300-01A series VFD for air compressor Product dimension A.3 Wall installation dimension Figure A-1 7.5kW–37kW wall installation diagram Figure A-2 45kW–55kW wall installation diagram -100-...
  • Page 106 Goodrive300-01A series VFD for air compressor Product dimension Figure A-3 75kW wall installation diagram Figure A-4 90kW–110kW wall installation diagram Figure A-5 132kW–200kW wall installation diagram -101-...
  • Page 107 Goodrive300-01A series VFD for air compressor Product dimension Figure A-6 220kW–315kW wall installation diagram Table A-1 Wall installation dimension of 7.5kW–315kW single VFD (unit: mm) Diameter of Power mounting hole 7.5kW 303.5 196.5 Ø 6 11kW–22kW 340.5 328.5 184.5 104.5 Ø...
  • Page 108 Goodrive300-01A series VFD for air compressor Product dimension Figure A-8 350kW–500kW floor installation diagram Table A-2 Floor installation dimension of 220kW–500kW single VFD (unit: mm) Diameter Power mounting hole 220kW–315kW 1410 1390 Ø 13/12 350kW–500kW 1700 1678 Ø 22/12 Figure A-9 Wall installation diagram of 7.5kW–15kW single VFD integrated machine Table A-3 Wall installation dimension of 7.5kW–15kW single-VFD integrated machine (unit: mm)
  • Page 109 Goodrive300-01A series VFD for air compressor Product dimension A.4 Flange installation dimension Figure A-10 7.5kW–55kW flange installation diagram Figure A-11 75kW flange installation diagram 4-R2 Figure A-12 90kW–110kW flange installation diagram -104-...
  • Page 110 Goodrive300-01A series VFD for air compressor Product dimension 4-R2 Figure A-13 132kW–200kW flange installation diagram Table A-4 7.5kW–200kW flange installation dimension (unit: mm) Diameter of Power W1 W2 W3 W4 H1 H2 mounting specification hole 7.5kW 191 151 174 11.5 370 351 324 12 196.5 113...
  • Page 111 Goodrive300-01A series VFD for air compressor Product dimension Table A-5 Flange installation dimension of 7.5kW–15kW single-VFD integrated machine (mm) Diameter of Power W1 W2 W3 W4 H1 H2 mounting specification hole 7.5kW–15kW 266 250 224 13 371 250 350.5 20.5 184.5 104 Ø...
  • Page 112 Goodrive300-01A series VFD for air compressor External optional accessories Appendix B External optional accessories B.1 RS485 LCD keypad B.1.1 LCD keypad introduction GD300-01A series VFD supports the use of the optional LCD keypad that uses RS485 communication. The LCD keypad can be used to control the start and stop of the VFD, read and write the status data, and set the parameters.
  • Page 113 Goodrive300-01A series VFD for air compressor External optional accessories Item Description LED off: in stopped state LED blinking: in parameter autotuning state Fault indicator. LED on: in fault state ② TRIP LED off: in normal state LED blinking: in pre-alarm state Shortcut key indicator, which displays different ③...
  • Page 114 Goodrive300-01A series VFD for air compressor External optional accessories Item Description In running state, you can press this key to stop running or autotuning. This key is restricted by ⑩ Stop/Reset key P07.04. In fault alarm state, this key can be used for reset in any control modes.
  • Page 115 Goodrive300-01A series VFD for air compressor External optional accessories 4-R12 Keypad installation bracket Installation dimensions Figure B-3 Keypad installation bracket B.1.3 RS485 communication cable B.1.3.1 Connection description Please use the provided RS485 communication cable, of which one end is connected to the keypad network port and the other is connected to the CN7 terminal of the VFD control board.
  • Page 116 Goodrive300-01A series VFD for air compressor External optional accessories B.1.3.2 Cable description Emergency stop signal Emergency stop signal Figure B-5 Emergency stop cable diagram Note: The emergency stop cable is used for emergency stop control when a device fault occurs and it is often connected to the S1 terminal and COM terminal.
  • Page 117 Goodrive300-01A series VFD for air compressor External optional accessories 03.17 16:02:35 PMSM air compressor system Software ver:V1.00 ConfigTB ver:V1.00 Enter Figure B-7 Initial interface B.1.4.2 Working environment interface The working environment interface displays certain parameters about the running. Device Status 03.17 16:02:35...
  • Page 118 Goodrive300-01A series VFD for air compressor External optional accessories Parameter Description Alarm: The alarm type is displayed in the pre-alarm area. When the temperature reaches the alarm threshold, the alarm is reported and the device stops. When the temperature reaches the pre-alarm threshold, the temperature is displayed in the pre-alarm area but the device continues running.
  • Page 119 Goodrive300-01A series VFD for air compressor External optional accessories 03.17 16:02:35 Reset Load Unload Start Stop Home Return Confirm Figure B-9 Setting interface In this interface, you can press the Up or Down key to select different operation functions. Then press OK for control;...
  • Page 120 Goodrive300-01A series VFD for air compressor External optional accessories 03.17 16:02:35 Real-time alarm 000. 03-17 16:00:05 xxx fault 001. 03-17 15:49:30 xxx fault 002. 03-17 15:08:20 xxx fault Home Return Figure B-10 Real-time alarm interface B.1.4.5 Main menu interface In the main interface, you can press...
  • Page 121 Goodrive300-01A series VFD for air compressor External optional accessories B.1.4.6 User parameter interface 1. Enter the user parameter interface through the main menu. 03.17 16:02:35 User param Set pressure xxx.xx Mpa Unloading pressure xxx.xx Mpa Loading pressure xxx.xx Mpa Setting Temp...
  • Page 122 Goodrive300-01A series VFD for air compressor External optional accessories User parameter Initial value Function After the startup, the air compressor runs with load with this Loading delay specified delay. If the manual mode is used, both load and unload need to be manually performed after the air compressor is started.
  • Page 123 Goodrive300-01A series VFD for air compressor External optional accessories User parameter Initial value Function started even though the scheduled startup time has been set.) Shutdown action: Disable/enable (Timed stop is valid only in Enabled state. Otherwise, the device is not automatically stopped even though the scheduled shutdown time has been set.)
  • Page 124 Goodrive300-01A series VFD for air compressor External optional accessories 03.17 16:02:35 Loading Pressure Set value xx.x Max. 020.00 MPa Min. 000.00 MPa Return Home Confirm Figure B-15 Loading pressure setting interface 03.17 16:02:35 Sleep Function Disable Enable Return Home Confirm Figure B-16 Sleep function selection interface 03.17 16:02:35...
  • Page 125 Goodrive300-01A series VFD for air compressor External optional accessories 03.17 16:02:35 Timing switch setting Mon. Tues. Wed. Thurs. Fri. Sat. Return Home Select Figure B-18 Date selection interface 03.17 16:02:35 Mon. Boot time ShutTime Boot Shutdown 0 0:0 0 0 0:0 0...
  • Page 126 Goodrive300-01A series VFD for air compressor External optional accessories B.1.4.7 Maintenance parameter interface 1. Enter the maintenance parameter interface through the main menu. 03.17 16:02:35 Maintain param Air filter set time xxxxxx h Oil filter set time xxxxxx h Splitter set time...
  • Page 127 Goodrive300-01A series VFD for air compressor External optional accessories Maintenance Initial Function parameter value Air filter run time It is cleared when a new air filter is used. Oil filter run time It is cleared when a new oil filter is used.
  • Page 128 Goodrive300-01A series VFD for air compressor External optional accessories 03.17 16:02:35 Oil filter run time Current value xxxxx Home Return Clear Figure B-24 Accumulative oil filter use time B.1.4.8 Protection parameter interface 1. Enter the protection parameter interface through the main menu.
  • Page 129 Goodrive300-01A series VFD for air compressor External optional accessories Protection Initial value Function parameter Prealarm When the actual air supply pressure is higher than this 0.90Mpa pressure pressure, a pre-alarm is reported. When the actual air supply pressure is higher than this Alarm pressure 1.00Mpa...
  • Page 130 Goodrive300-01A series VFD for air compressor External optional accessories 03.17 16:02:35 Please enter current password: Return Home Confirm Figure B-26 Administrator password input interface 03.17 16:02:35 Alarm Pressure Set value xx.x Max. 020.00 MPa Min. 000.00 MPa Return Home Confirm Figure B-27 Alarm pressure parameter setting interface 03.17 16:02:35...
  • Page 131 Goodrive300-01A series VFD for air compressor External optional accessories 03.17 16:02:35 Run information Master Home Return Select Figure B-29 Running information interface 03.17 16:02:35 Master running info Output Current xxxx.x A Output Voltage xxxxxx V Motor Speed xxxxxx rpm Output Freq xxx.xx Hz...
  • Page 132 Goodrive300-01A series VFD for air compressor External optional accessories 03.17 16:02:35 Master Param Max Ouput Freq xxx.xx Hz Run Freq Up limit xxx.xx Hz Run Freq Down limit xxx.xx Hz Load Run Low Limit Freq xxx.xx Hz No-load Run Freq xxx.xx Hz...
  • Page 133 Goodrive300-01A series VFD for air compressor External optional accessories Master parameter Initial value Function Running frequency It indicates the upper limit of the output 50.00Hz upper limit frequency of the VFD. Running frequency It indicates the lower limit of the output 00.00Hz...
  • Page 134 Goodrive300-01A series VFD for air compressor External optional accessories 03.17 16:02:35 Differential time Set value xx.x Max. 010.00 s Min. 000.00 s Home Return Confirm Figure B-35 Differential time setting interface B.1.4.11 Fan parameter interface 1. Enter the fan parameter interface through the main menu.
  • Page 135 Goodrive300-01A series VFD for air compressor External optional accessories Fan parameter Initial value Function Phase B current Setting range: 0.0–150.0% calibration coefficient Note: When parameters are restored to the factory settings, this value is remained. Phase C current calibration coefficient 2.
  • Page 136 Goodrive300-01A series VFD for air compressor External optional accessories B.1.5 Fault records The fault record interface is used to display the fault and alarm information about current device running. If an alarm is reported, alarm information is displayed. Fault records include VFD faults, air compressor faults, real-time alarms, and historic alarms.
  • Page 137 Goodrive300-01A series VFD for air compressor External optional accessories B.1.5.2 Air compressor fault interface This interface displays air compressor exception information, including the air filter, oil filter, and separator blockage, maintenance need, and auxiliary pressure or temperature pre-alarm or alarm.
  • Page 138 Goodrive300-01A series VFD for air compressor External optional accessories 03.17 16:02:35 Please enter current password: Home Return Confirm 03.17 16:02:35 Confirm to clear the realtime alarm info? Return Home Confirm Figure B-44 Alarm record clearing interface Note: The real-time alarm interface can keep a maximum of 120 fault records due to the restriction of memory.
  • Page 139 Goodrive300-01A series VFD for air compressor External optional accessories 03.17 16:02:35 VFD information Master Home Return Select Figure B-45 VFD information interface 03.17 16:02:35 Master VFD info Ctrl Board Software Ver xxx.xx Present Temperature xxxx.x Digital Input Terminal State xxxxxx...
  • Page 140 Goodrive300-01A series VFD for air compressor External optional accessories Note:  Fan VFD information can be information only about Goodrive300-21 series VFD.  VFD information is read only. B.1.7 System configuration Enter a correct factory password to enter the system configuration interface.
  • Page 141 Goodrive300-01A series VFD for air compressor External optional accessories 03.17 16:02:35 Master param setting Motor type Max frequency 050.00 Mpa Rated power 0090.0 kW Rated frequency 050.00 Hz Rated voltage 000380 V Rated current 0176.0 A Return Home Edit 03.17 16:02:35 Master param setting 00.030 Ω...
  • Page 142 Goodrive300-01A series VFD for air compressor External optional accessories Step 4 Enter the commissioning mode. Run the master and fan in jogging mode to check the motor rotation direction. Step 5 Adjust user parameters, factory parameters, and maintenance parameters according to the manual.
  • Page 143 Goodrive300-01A series VFD for air compressor External optional accessories 03.17 16:02:35 03.17 16:02:35 Modify password Modify password Please enter current password: Please enter new password: Note:The setting rage of password is 0-9999 Return Home Confirm Return Home Confirm 03.17 16:02:35 03.17 16:02:35...
  • Page 144 Goodrive300-01A series VFD for air compressor External optional accessories 03.17 16:02:35 03.17 16:02:35 Backlight setting Brightness setting Brightness setting Set value: Time setting Note: When it is set to 0,the brightness setting function is invalid Return Home Select Return Home...
  • Page 145 Goodrive300-01A series VFD for air compressor External optional accessories Figure B-57 lists the supported VFD series. In future, more VFD series may be supported. 03.17 16:02:35 VFD model GD300-01A GD300-21(Master) GD300-21(Fan) GD300-01A-RT Return Home Select Figure B-57 VFD model selection interface B.1.7.8 Parameter copying...
  • Page 146 Goodrive300-01A series VFD for air compressor External optional accessories B.2 TC070A touch screen B.2.1 Specifications Table B-4 Touch screen specifications Category Item Specifications 7” 16:9 TFT LCD screen Screen Resolution 800×480 Color 24 bits Brightness 360 cd/m² Backlight LCD lifetime...
  • Page 147 2.5-meter long. Communication function Communication mode GPRS, plug 34008-00097 module directly Note: Users can choose the optional INVT ICA200 series IoT module. For details, refer to section B.3. B.2.2 Connection terminals USB Host Power supply RS485 serial DB9 serial port...
  • Page 148 Goodrive300-01A series VFD for air compressor External optional accessories Pin5 Pin6 Rx+(A) Pin7 RxD (COM3 RS232) Pin8 TxD (COM3 RS232) Pin9 RS485 terminals (Pins 1–2, from left to right) Pin1 A+ (COM2 RS485) Pin2 B- (COM2 RS485) USB Host Used to connect external peripherals such as...
  • Page 149 Goodrive300-01A series VFD for air compressor External optional accessories B.2.4 Cable description Emergency stop signal Emergency stop signal Figure B-61 Emergency stop cable diagram Note: The emergency stop cable is used for emergency stop control when a device fault occurs and it is often connected to the S1 terminal and COM terminal.
  • Page 150 Goodrive300-01A series VFD for air compressor External optional accessories B.2.5 Installation dimensions and description B.2.5.1 Touch screen installation dimensions 203.9± 0.5 190.8± 0.5 13.1 71.4± 0.5 33.8± 0.3 7.3± 0.3 Embedded installation Snap-fit fastening position 4 in total Figure B-64 Touch screen installation dimensions (unit: mm) B.2.5.2 Cut-out installation description...
  • Page 151 Bottom B.3 IoT module B.3.1 Product overview INVT ICA series communication adapter is a kind of wireless data terminal for Internet of Things (IoT), which provides users with wireless long-distance data transmission function through the public operator network. a) Wall-mounted...
  • Page 152  Support GPRS base station positioning.  GPS satellite positioning for acquiring accurate device location in real-time (optional). B.3.1.2 Model instruction Model name illustration of INVT communication adapters for the IoT: ICA 2 0 0-0 0 G-5 ① ②...
  • Page 153 Goodrive300-01A series VFD for air compressor External optional accessories Field Symbol Description Content 0: IP00 (No housing); 1: IP20 (wall-mounted housing); ⑥ Protection level Protection level 2: IP20 (rail-mounted housing); 6: IP65 (direct-insert housing). Special function G: With GPS ⑦...
  • Page 154 Goodrive300-01A series VFD for air compressor External optional accessories Category Name Detailed instruction ARM 32-bit Cortex™-M3 CPU resources FLASH 512KB flash SRAM 64KB Peripheral interface RS232; RS485; GPRS; GPS; Wireless module Industrial-level wireless module Support four frequencies of GSM850/900/1800/1900MHz •GPRS multi-slot class 12/10 •GPRS mobile station class B...
  • Page 155 Goodrive300-01A series VFD for air compressor External optional accessories B.3.2 Installation dimensions Only properly installed adapter can achieve designed functions. The adapter must be installed by qualified electricians recognized by our company. Note: The adapter must be installed with power off.
  • Page 156 Goodrive300-01A series VFD for air compressor External optional accessories  Below is the outline dimension for IP20 model (rail-mounted housing) (unit: mm). Figure B-68 Outline dimension for IP20 model (rail-mounted housing) B.3.3 Operational guide The module is usually applied in complicated environment. To cope with the complex application conditions and ensure system stability, the power must be above 3W and in stable status (the ripple is under 100mA).
  • Page 157 Goodrive300-01A series VFD for air compressor External optional accessories B.4 Fan control protector B.4.1 Model instruction MCP100 - 015 ① ② ③ Field Symbol Description Content ① Category Product series MCP: Fan protection controller Type of current 100: Basic (digital feedback) ②...
  • Page 158 Goodrive300-01A series VFD for air compressor External optional accessories Terminal Category Name Terminal function sign Reference 24V, RLY, CTA/Y1, CTB, CTC reference ground ground Fan start/stop control terminal 1. When start/stop of the fan is controlled by Y terminal, cut off the fan output when the VFD Y output signal is valid and connect the fan when the VFD Y output signal is invalid.
  • Page 159 Goodrive300-01A series VFD for air compressor External optional accessories Note: 1. The rated current of the fan protection module must be greater than the rated current of the fan. 2. The rated current of the fan cannot exceed 10A due to the limitation of the load carrying capacity of the fan protection module.
  • Page 160 Goodrive300-01A series VFD for air compressor External optional accessories blown and needs to be replaced before it can be used again. When overcurrent is triggered, the fault signal is sent to the VFD through the S1 terminal, and the VFD stops and shuts down the fan through RO3.
  • Page 161 Goodrive300-01A series VFD for air compressor External optional accessories VFD model Input filter Output filter GD300-01A-015G-4-CT GD300-01A-018G-4 GD300-01A-022G-4 FLT-P04065L-B FLT-L04065L-B GD300-01A-030G-4 GD300-01A-037G-4 FLT-P04100L-B FLT-L04100L-B GD300-01A-045G-4 GD300-01A-055G-4 FLT-P04150L-B FLT-L04150L-B GD300-01A-075G-4 GD300-01A-090G-4 GD300-01A-110G-4 FLT-P04240L-B FLT-L04240L-B GD300-01A-132G-4 GD300-01A-160G-4 GD300-01A-185G-4 FLT-P04400L-B FLT-L04400L-B GD300-01A-200G-4 GD300-01A-220G-4...
  • Page 162 Goodrive300-01A series VFD for air compressor Current transformer of the fan Appendix C Current transformer of the fan C.1 Current transformer model selections Power of the cooling Rated current A of Recommended transformation ratio fan (kW) cooling fan of the transformer 0.75...
  • Page 163 Goodrive300-01A series VFD for air compressor Current transformer of the fan to GD300-01A control board S1 S2 S1 S2 相 相 Cables on fan side Cables on fan side R/A phase S/B phase Dotted terminal of current transformer current transformer current transformer Pay attention to the current direction during wiring.
  • Page 164 Goodrive300-01A series VFD for air compressor Communication protocol Appendix D Communication protocol D.1 Application mode The Modbus protocol of this VFD is RTU mode and the network line is RS485. The interface of RS485 works on semiduplex and its data signal adopts differential transmission mode which is also called balance transmission, too.
  • Page 165 Goodrive300-01A series VFD for air compressor Communication protocol D.2.4 Definition of data address The address definition of communication data is used to control VFD operations, obtain VFD state information and set function parameters. D.2.4.1 Rules for presentation of function code address The parameter address occupies 2 bytes with the most significant byte (MSB) in the front and the least significant byte (LSB) in the behind.
  • Page 166 Goodrive300-01A series VFD for air compressor Communication protocol Function Address Data meaning description definition attribute Upper limit torque of brake torque (0–3000, 2008H 1000 corresponds to 100.0% rated motor current) Special control command word: Bit0–1: =00: Motor 1 =01: Motor 2...
  • Page 167 Goodrive300-01A series VFD for air compressor Communication protocol Function Address Data meaning description definition attribute The set maintenance time of part 1; 2010H Range: 0–65535 The set maintenance time of part 2; 2011H Range: 0–65535 The set maintenance time of part 3;...
  • Page 168 Goodrive300-01A series VFD for air compressor Communication protocol Function Address Data meaning description definition attribute Running 3000H frequency The set frequency 3001H Bus voltage 3002H Output voltage 3003H Output current 3004H Running speed 3005H Output power 3006H Output torque 3007H...
  • Page 169 Goodrive300-01A series VFD for air compressor Communication protocol D.2.5 Error message response Table D-2 Error message response and meaning Code Name Meaning The command from master cannot be executed. The reason maybe: Illegal command 1. This command is only for new version and this version cannot realize.
  • Page 170 Goodrive300-01A series VFD for air compressor Communication protocol 0 0 0 0 0 0 1 1 (Hex 03H) For normal responses, the slave responds the same codes, while for objection responses, it will return: 1 0 0 0 0 0 1 1 (Hex 83H) Besides the function codes modification for the objection fault, the slave will respond a byte of abnormal code which defines the error reason.
  • Page 171 Goodrive300-01A series VFD for air compressor Common EMC problems and troubleshooting Appendix E Common EMC problems and troubleshooting E.1 Interference problems of meter switches and sensors The sensor signal (pressure, temperature, displacement, etc.) is collected and displayed via HMI device, the sensor value displayed after VFD starts is wrong, the common phenomena are listed below: ...
  • Page 172 Goodrive300-01A series VFD for air compressor Common EMC problems and troubleshooting  The communication cable cannot be routed with motor cable in the same cable tray;  In multi-machine application, the connection of communication cables between VFDs should adopt chrysanthemum mode to improve anti-interference ability;...
  • Page 173 Goodrive300-01A series VFD for air compressor Common EMC problems and troubleshooting E.4 Leakage current and residual current device (RCD) As the VFD outputs high frequency PWM voltage to drive the motor, the distributed capacitance against the radiator from internal IGBT and between rotor and stator of the motor may cause the VFD to generate high frequency leakage current against the ground.
  • Page 174 Goodrive300-01A series VFD for air compressor Common EMC problems and troubleshooting in which the first two steps is to measure the resistance of motor stator/rotor while the VFD will output square wave to motor stator winding at 4kHz (default carrier frequency), as leakage current generated by 4kHz carrier frequency against distributed capacitance between motor rotor and stator during charging/discharging is quite obvious, which may cause mal-operation of RCD.
  • Page 175 6 6 0 0 1 - 0 0 5 5 3...

Table of Contents
