Goodrive350-19 Series VFD for Crane
Function
Name
code
EtherNet IP
P16.54
communication
timeout period
EtherNet IP
P16.55
communication rate
P16.56–
Reserved
P16.57
P16.58
Industrial Ethernet 0–255
Description
25: Status word 2
26: HDIB frequency value (×100, kHz)
27: PG card pulse feedback count high bit
28: PG card pulse feedback count low bit
29: Brake status
30: Non-standard status
31: Reserved
32: Encoder feedback frequency
(-Fmax–Fmax, unit: 0.01Hz)
33–51: Reserved
52: Module temperature
53: U-phase current transient value
54: V-phase current transient value
55: W-phase current transient value
56–57: Reserved
58: Load weight
59: Current peak value
60: Filter torque setting (filter after running)
61: MWh electromotive status (MSB)
62: kWh status (LSB) (*10,kWh)
63: MWh electricity generation status (MSB)
64: kWh electricity generation status (LSB)
(*10,kWh)
65: PG card pulse reference count high bit
66: PG card pulse reference count low bit
67: Function parameter mapping
(PZD2–PZD12 correspond to P14.60– P14.70)
0.0 (invalid)–60.0s
When EtherNet IP communication fault occurs,
the VFD reports an EtherNet IP communication
fault (E-EIP).
0: Self adaptive
1: 100 M full duplex
2: 100 M half duplex
3: 10 M full duplex
4: 10 M half duplex
0–65535
-246-
Function parameters
Default Modify
○
5.0s
◎
0
●
0
◎
192
