INVT Goodrive350-19 Series Operation Manual page 183

Goodrive350-19 Series VFD for Crane
Function
Name
code
factor of motor 1
Oscillation control
P04.12
threshold of motor 1
V/F curve setting of
P04.13
motor 2
Torque boost of
P04.14
motor 2
Torque boost cut-off
P04.15
of motor 2
V/F frequency point
P04.16
1 of motor 2
V/F voltage point 1
P04.17
of motor 2
V/F frequency point
P04.18
2 of motor 2
V/F voltage point 2
P04.19
of motor 2
V/F frequency point
P04.20
3 of motor 2
V/F voltage point 3
P04.21
of motor 2
V/F slip
P04.22 compensation gain
of motor 2
Description
adjust the two function codes properly to
eliminate such phenomenon.
Setting range of P04.10: 0–100
Setting range of P04.11: 0–100
Setting range of P04.12: 0.00Hz–P00.03 (Max.
output frequency)
This group of function code defines the V/F
curve of motor 2 to meet the needs of different
loads.
0: Straight-line V/F curve
1: Multi-point V/F curve
2: Torque-down V/F curve (power of 1.3)
3: Torque-down V/F curve (power of 1.7)
4: Torque-down V/F curve (power of 2.0)
5: Customized V/F curve (V/F separation)
Note: Refer to the description for P04.00.
Setting range of P04.14: 0.0%: Automatic;
0.1%–10.0%
Setting range of P04.15: 0.0%–50.0% (of the
rated frequency of motor 2)
Note: Refer to the descriptions for P04.01
and P04.02.
P04.16 setting range: 0.00Hz–P04.18
Setting range of P04.17: 0.0%–110.0% (of the
rated voltage of motor 2)
Setting range of P04.18: P04.16–P04.20
Setting range of P04.19: 0.0%–110.0% (of the
rated voltage of motor 2)
Setting range of
(Rated frequency of AM 2) or P04.18– P12.16
(Rated frequency of SM 2)
Setting range of P04.21: 0.0%–110.0% (of the
rated voltage of motor 2)
Note: Refer to the descriptions for P04.03
and P04.08.
Used to compensate for the motor rotating
speed change caused by load change in the
space voltage vector mode, and thus improve
-171-
P04.20: P04.18–P12.02
Function parameters
Default Modify
○
30.00Hz
◎
0
○
0.0%
○
20.0%
○
0.00Hz
○
00.0%
○
0.00Hz
○
00.0%
○
0.00Hz
○
00.0%
○
0.0%
