When the altitude exceeds 1000m, derate by 1% for every increase of 100m. When the altitude
exceeds 3000m, consult the local INVT dealer INVT office for details.
B.2.2.3 Derating due to carrier frequency
The VFDs in different power classes are different in carrier frequency. The rated power of a VFD is
defined based on the carrier frequency set in factory. If the carrier frequency exceeds the factory
setting, the power of the VFD is derated by 10% for each increased 1 kHz.
B.3 Grid specifications
AC 3PH 380V(-15%) – 440V(+10%)
Grid voltage
AC 3PH 520V(-15%) – 690V(+10%)
According to the definition in IEC 61439-1, the maximum allowable short-circuit
Short-circuit
current at the incoming end is 100 kA. Therefore, the VFD is applicable to
scenarios where the transmitted current in the circuit is no larger than 100kA when
capacity
the VFD runs at the maximum rated voltage.
50/60Hz±5%, with a maximum change rate of 20%/s
Frequency
B.4 Motor connection data
Motor type Asynchronous induction motor or permanent-magnet synchronous motor
0–U1 (motor rated voltage), 3PH symmetrical, Umax (VFD rated voltage) at the
Voltage
field-weakening point
Short-circuit The motor output short-circuit protection meets the requirements of IEC
protection 61800-5-1.
Frequency 0–400 Hz
Frequency
0.01Hz
resolution
Current See section 3.6 Product ratings.
Power limit 1.5 times of the rated power of the motor
Field-weakening
10...400Hz
point
Carrier
4, 8, 12, or 15kHz
frequency
B.5 Application standards
The following table describes the standards that VFDs comply with.
EN/ISO 13849-1
IEC/EN 60204-1
IEC/EN 62061
Safety of machinery—Safety-related parts of control systems—Part 1:
General principles for design
Safety of machinery—Electrical
1:General requirements
Safety of machinery—Safety-related functional safety of electrical,
electronic, and programmable electronic control systems
equipment
-462-
Technical data
of machines—Part
