Goodrive350-19 Series VFD for Crane
The rated input voltage drop of input reactor is designed to 1.5%.
The rated output voltage drop of output reactor is designed to 1%.
For the model selection for paralleled VFDs, see the operation manual for Goodrive series
VFDs in parallel connection.
VFD power
22kW
30kW
37kW
45kW
55kW
75kW
90kW
110kW
132kW
160kW
185kW
200kW
220kW
250kW
280kW
315kW
355kW
400kW
450kW
500kW
560kW
630kW
Note: The input voltage of the passive harmonic filter for 660V VFD is 660–690V, 50Hz.
D.8 Filter
J10 is not connected in factory for the 380V 110kW and lower VFD models. Connect the J10
packaged with the manual if the requirements of level C3 need to be met. J10 is connected in factory
for the 380V 132kW and higher VFD models, all of which meet the requirements of level C3.
Disconnect J10 in any of the following situations:
Table D-9 Filter model selection for 660V VFDs
Input filter
Passive harmonic
filter
GDL-H0035-6AL
GDL-H0047-6AL
GDL-H0047-6AL
GDL-H0060-6AL
GDL-H0090-6AL
GDL-H0090-6AL
GDL-H0110-6AL
GDL-H0150-6AL
GDL-H0150-6AL
GDL-H0200-6AL
GDL-H0200-6AL
GDL-H0250-6AL
GDL-H0250-6AL
GDL-H0300-6AL
GDL-H0300-6AL
GDL-H0400-6AL
GDL-H0400-6AL
GDL-H0480-6AL
GDL-H0480-6AL
GDL-H0600-6AL
GDL-H0600-6AL
GDL-H0800-6AL
Output filter
dv/dt filter
GDL-DUL0030-6CU
GDL-DUL0045-6CU
GDL-DUL0045-6CU
GDL-DUL0065-6CU
GDL-DUL0065-6CU
GDL-DUL0090-6CU
GDL-DUL0110-6CU
GDL-DUL0150-6CU
GDL-DUL0150-6CU
GDL-DUL0220-6CU
GDL-DUL0220-6CU
GDL-DUL0220-6CU
GDL-DUL0260-6CU
GDL-DUL0320-6CU
GDL-DUL0320-6CU
GDL-DUL0400-6CU
GDL-DUL0400-6CU
GDL-DUL0480-6CU
GDL-DUL0480-6CU
GDL-DUL0600-6CU
GDL-DUL0600-6CU
GDL-DUL0800-6CU
-507-
Optional peripheral accessories
Sine-wave filter
GDL-OSF0030-6CU
GDL-OSF0045-6CU
GDL-OSF0045-6CU
GDL-OSF0065-6CU
GDL-OSF0065-6CU
GDL-OSF0090-6CU
GDL-OSF0110-6CU
GDL-OSF0150-6CU
GDL-OSF0150-6CU
GDL-OSF0200-6CU
GDL-OSF0200-6CU
GDL-OSF0250-6CU
GDL-OSF0250-6CU
GDL-OSF0300-6CU
GDL-OSF0300-6CU
GDL-OSF0400-6CU
GDL-OSF0400-6CU
GDL-OSF0480-6CU
GDL-OSF0480-6CU
GDL-OSF0600-6CU
GDL-OSF0600-6CU
GDL-OSF0800-6CU
