INVT Goodrive350-19 Series Operation Manual page 295

Goodrive350-19 Series VFD for Crane
Function
Name
code
HDI3 high-speed
P25.40 pulse input function
selection
HDI3 lower limit
P25.41
frequency
Corresponding
setting of HDI3
P25.42
lower limit
frequency
HDI3 upper limit
P25.43
frequency
Corresponding
setting of HDI3
P25.44
upper limit
frequency
HDI3 frequency
P25.45
input filter time
AI3 input signal
P25.46
type
S terminal power
signal selection (I/O
P25.48
card 2)
Group P26––I/O card output functions
Function
Name
code
P26.00 HDO2 output type
HDO2 output
P26.01
selection
P26.02 Y2 output selection
Description
P25.32/P25.37
P25.30/P25.35–10.00V
P25.33/P25.38 setting range: -300.0%–300.0%
P25.34/P25.39 setting range: 0.000s–10.000s
0–1
0: Input set through frequency
1: Counting
0.000kHz–P25.43
-300.0–300.0%
P25.41–50.000kHz
-300.0–300.0%
0.000–10.000s
0–1
0: Voltage
1: Current
0–1
0: DC (24–48V DC)
1: AC (24–48V AC)
Description
0: Open collector high-speed pulse output
1: Open collector output
Same as the description for P06.01
-283-
setting range:
Function parameters
Default Modify
◎
0
○
0.000kHz
○
0.0%
50.000
○
kHz
○
100.0%
○
0.030s
○
0
◎
0
Default Modify
◎
0
○
0
○
0
