Goodrive350-19 Series VFD for Crane
Terminal
Category
symbol
S8—COM
Y2—CME
Relay output
A.5 Communication cards
A.5.1 WIFI communication card (EC-TX502)
Definition of indicators and function keys:
Indicator
LED3
LED5
Terminal name
Digital input 4
Digital output
RO3A
NO contact of relay 3
RO3B
NC contact of relay 3
Common contact of
RO3C
relay 3
RO4A
NO contact of relay 4
Common contact of
RO4C
relay 4
Definition
WIFI status indicator
Power indicator
S8 supports PTC input, while PTC acts at
2.5kΩ. It supports internal pull-up of +24V,
and it supports the input of only dry contacts
sharing COM. The max. input frequency is
50Hz.
1.
Switch capacity: 50mA/30V
2.
Output frequency range: 0–1kHz
3.
The terminals CME and COM are
shorted through J3 before delivery.
1.
Contact
1A/DC30V
2.
Cannot be used as high frequency
digital output.
On: The expansion card is connecting with the control
board.
Blinks periodically (cycle: 1s; on: 0.5s; off: 0.5s): The
expansion card is connected with the control board.
Off: The expansion card is disconnected from the
control board.
This indicator is on after the control board feeds power
to the communication card.
-424-
Expansion card
Description
capacity:
Function
3A/AC250V,
