Goodrive350-19 Series VFD for Crane
Function
code
Channel selection for
P14.48 mapping between PZDs
and function codes
Mapped function code of
P14.49
Mapped function code of
P14.50
Mapped function code of
P14.51
P14.52 Mapped function code of
P14.53 Mapped function code of
P14.54 Mapped function code of
P14.55 Mapped function code of
P14.56 Mapped function code of
P14.57 Mapped function code of
P14.58 Mapped function code of
P14.59 Mapped function code of
Name
received PZD2
received PZD3
received PZD4
received PZD5
received PZD6
received PZD7
received PZD8
received PZD9
received PZD10
received PZD11
received PZD12
Short description of communication PZD
Description
0x00–0x12
Ones place: Channel for mapping
function codes to PZDs
0: Reserved
1: Group P15
2: Group P16
Tens place: Save function at power off
0: Disable
1: Enable
0x0000–0xFFFF
Set the function code address to be
mapped. For example, if the parameter to
be mapped is P85.04, set it to 0x5504.
0x0000–0xFFFF
0x0000–0xFFFF
0x0000–0xFFFF
0x0000–0xFFFF
0x0000–0xFFFF
0x0000–0xFFFF
0x0000–0xFFFF
0x0000–0xFFFF
0x0000–0xFFFF
0x0000–0xFFFF
-405-
Setting
0x11
0x0000
0x0000
0x0000
0x0000
0x0000
0x0000
0x0000
0x0000
0x0000
0x0000
0x0000
