INVT Goodrive350-19 Series Operation Manual page 206

Goodrive350-19 Series VFD for Crane
Function
Name
code
coefficient
Rotational speed
P07.09
display coefficient
Linear speed
P07.10
display coefficient
Rectifier bridge
P07.11
temperature
Inverter module
P07.12
temperature
Control board
P07.13
software version
Local accumulative
P07.14
running time
VFD electricity
P07.15 consumption high
bits
VFD electricity
P07.16 consumption low
bits
P07.17 VFD model
P07.18 VFD rated power 0.4–3000.0kW
P07.19 VFD rated voltage 50–1200V
P07.20 VFD rated current 0.1–6000.0A
P07.21 Factory bar code 1 0x0000–0xFFFF
P07.22 Factory bar code 2 0x0000–0xFFFF
P07.23 Factory bar code 3 0x0000–0xFFFF
Description
Display frequency = Running frequency *
P07.08
0.1–999.9%
Mechanical rotation speed = 120 × (Displayed
running frequency) × P07.09/(Number of motor
pole pairs)
0.1–999.9%
Linear speed = (Mechanical rotation speed) ×
P07.10
-20.0–120.0° C
-20.0–120.0° C
1.00–655.35
0–65535h
Used to display the electricity consumption of
the VFD
VFD electricity consumption = P07.15*1000 +
P07.16
Setting range of P07.15: 0–65535 kWh (*1000)
Setting range of P07.16: 0.0–999.9kWh
0x0000–0xFFF1
Ones place: G/P type
0: G type
1: P type
Tens place: Chip type
0: DSP
1: ARM
Hundreds place–thousands place: Reserved
-194-
Function parameters
Default Modify
○
100.0%
○
1.0%
●
/
/
●
/
●
/
●
/
●
/
●
●
0x0000
●
/
●
/
●
/
●
/
●
/
●
/
