Goodrive350-19 Series VFD for Crane
condition is holding brake in speed mode. The main relevant parameters are listed in the following.
Function
code
P90.04
Enabling brake-oriented logic
Enabling forward torque for
P90.05
reverse-running start/stop
P90.12
Forward brake release current
P90.13
Reverse brake release current
P90.14
Forward brake release torque 0.0–200.0% (of the motor rated torque)
P90.15
Reverse brake release torque 0.0–200.0% (of the motor rated torque)
Forward brake release
P90.16
Reverse brake release
P90.17
Forward brake closing
P90.18
P90.19
Reverse brake closing
Name
0–1
0: The brake is controlled by an
external controller.
1: The brake is controlled by the VFD.
0x00–0x11
Ones place: indicates whether to
enable forward torque for
reverse-running start
0: Disable (The reverse-running start
direction is consistent with the
command.)
1: Enable (The reverse-running start
direction is always the forward-running
direction.)
Tens place: indicates whether to
enable forward torque for
reverse-running stop
0: Disable (The reverse-running stop
direction is consistent with the
command.)
1: Enable (The reverse-running stop
direction is always the forward-running
direction.)
0.0–200.0% (of the motor rated
current)
0.0–200.0% (of the motor rated
current)
0.00–20.00Hz
frequency
0.00–20.00Hz
frequency
0.00–20.00Hz
frequency
0.00–20.00Hz
Description
-45-
Commissioning guidelines
Default
0
0x00
0.0%
0.0%
0.0%
0.0%
3.00Hz
3.00Hz
3.00Hz
3.00Hz
