Goodrive350-19 Series VFD for Crane
Function description
Relay output
I/O
Digital input
expansion
card 2
PT100 input
PT1000 input
Mounting method Supports wall-mounting, floor-mounting and flange-mounting.
Temperature of
environment
Ingress protection
(IP) rating
Pollution degree Degree 2
Cooling method Forced air cooling
Other
DC reactor
Braking unit
EMC filter
The 1.5–5.5kW VFD models support two expansion cards at
most at the same time.
The 7.5kW and higher VFD models support three expansion
cards at most at the same time.
Two programmable relay outputs. Contact capacity: 3A/250VAC,
1A/30VDC
RO3A: NO; RO3C: common; RO4A: NO; RO4C: common
Three regular inputs
Internal impedance: 6.6kΩ
Max. input frequency: 1kHz
Supporting the internal power 24V
Supporting the voltage input of external power
(-20%)24–48VDC(+10%) and (-10%)24–48VAC(+10%)
Bidirectional input terminals, simultaneously supporting NPN and
PNP connection methods
One channel supports PTC input, while PTC acts at 2.5kΩ, and
supports the input of only dry contacts sharing COM
Independent PT100 and PT1000 input:
1. Resolution rate: 1° C
2. Range: -20° C–150° C
3. Detection precision: ±3° C
4. Supporting offline protection
-10° C – 50° C. Derating is required when the ambient
running
temperature exceeds 40° C.
IP20
Standard built-in part for 380V 18.5–110kW VFD models.
Optional external part for 380V 132kW and higher models and for
660V models.
Standard built-in part for 380V 110kW and lower VFD models.
Optional external part for 660V models.
C3 filters are optional parts and can be built in the VFD.
If a C3 filter is required, connect the jumper J10. After the C3
filter is configured, the VFD can meet IEC61800-3 C3
requirements.
Optional external filters can be used to meet the IEC61800-3 C2
Specifications
-15-
Product overview
