Goodrive350-19 Series VFD for Crane
Terminal symbol
4-Pin terminal
CN5
SIM
Indicator meaning:
Indicator
LED1/ED2 3.8V power indicator On: The expansion card is powered on.
LED3 4G network indicator
Handshaking
LED4
LED5 Run indicator
A.8 Power supply expansion cards
A.8.1 24V power supply expansion card (EC-PS501-24)
Indicator definition:
Indicator Definition
24V power
LED1
LED2
The 24V power supply card is mainly used to connect to external 24V power to power the control
board, avoiding to apply electricity for independent control board commissioning. During wiring,
connect to +24V and COM according to the CN2 sign.
Description
RS485 communication
interface
Antenna
SIM card socket
Definition
Fast flashing (on 0.6s; off 0.6s): No SIM card/SIM
PIN/Network registration in progress/Registration failed
Slow flashing (on: 75ms; off: 3000ms): Standby.
Quick flashing (on: 75ms; off: 75ms): Data link established.
Blinking with an interval of 1s: The expansion card is
indicator connected with the control board.
On: Abnormal running.
Blinking with an interval of 1s: Normal running.
Off: Abnormal running.
Indicator for the external 24V power.
indicator
5V power Indicator for the 5V power that is provided for the control board
indicator after the switch power converts external power.
The terminals are 24V, GND, 485+, and 485-
respectively.
4G antenna terminal
For SIM card installation
Function
Function
