INVT Goodrive350-19 Series Operation Manual page 485

Goodrive350-19 Series VFD for Crane
C.6 Dimensions of AC 3PH 520V (-15%)–690V (+10%)
C.6.1 Wall-mounting dimensions
H1 H2
VFD model
22–45kW
55–132kW
W1
H1
Figure C-17 Wall mounting for 660V 160–220kW VFD models
VFD model
160–220kW
W1
W2
Figure C-16 Wall mounting for 660V 22–132kW VFD models
Outline dimensions
(mm)
W1 H1 D1
270 557 325
325 682 365
Outline dimensions (mm)
W1 H1
500 872
Mount
dimensions (mm)
W2 H2
130 540
200 661
D1
Installation
dimension (mm)
D1 W2 H2
360 180 850
-473-
Dimension drawings
D1
Hole
diameter Screw
(mm)
ø 7 M6
ø 9.5 M8
W2
6- ø11.0
H2
Installation
Hole Fixed
diameter Screw
(mm)
ø 11 M10
Net Gross
weight weight
(kg) (kg)
30 32
47 67
W2
Net Gross
weight weight
(kg) (kg)
85 110
