Summary of Contents for INVT Goodrive100-PV Series

  • Page 1 Goodrive100-PV Series Solar Pumping VFD...

  • Page 2: Table Of Contents

    Goodrive100-PV Series Solar Pumping VFD Contents Contents Contents ............................ i 1 Safety precautions ....................... 1 1.1 Safety definition ......................1 1.2 Warning symbols ......................1 1.3 Safety guidelines ......................2 2 Product overview........................4 2.1 Unpacking inspection ....................4 2.2 Name plate ........................4 2.3 Type designation key .....................

  • Page 3: Safety Precautions

    Goodrive100-PV Series Solar Pumping VFD Safety precautions 1 Safety precautions Please read this manual carefully and follow all safety precautions before moving, installing, operating and servicing the variable-frequency drive (VFD). If ignored, physical injury or death may occur, or damage may occur to the devices.

  • Page 4: Safety Guidelines

    Goodrive100-PV Series Solar Pumping VFD Safety precautions 1.3 Safety guidelines  Only qualified electricians are allowed to operate on the VFD.  Do not carry out any wiring and inspection or changing components when the power supply is applied. Ensure all input power supply is disconnected before wiring and checking and always wait for at least the time designated on the VFD or until the DC bus voltage is less than 36V.
  • Page 5 Goodrive100-PV Series Solar Pumping VFD Safety precautions  (+) and (-) are DC power supply input terminals. R, S and T (L,N) are AC power supply input terminals. U, V and W are output terminals. Please connect the input power cables and motor cables with proper techniques;...

  • Page 6: Product Overview

    Goodrive100-PV Series Solar Pumping VFD Product overview 2 Product overview 2.1 Unpacking inspection Check as follows after receiving products: 1. Check that there are no damage and humidification to the package. If not, please contact with local agents or offices.

  • Page 7: Product Specifications

    Goodrive100-PV Series Solar Pumping VFD Product overview Sign Description Remarks Product Product GD100 is short for Goodrive100. ① abbreviation abbreviation Power range 5R5G—5.5kW Rated power ② + Load type G—Constant torque load 4: AC 3PH 380V (-15%)–440(+10%) 2: AC 3PH 220V (-15%)–240(+10%)
  • Page 8 Goodrive100-PV Series Solar Pumping VFD Product overview Rated Rated output Rated output Max. DC input Series Model input power current (A) current (A) current (A) (Kw) Input/output GD100-1R5G-SS2-PV 15.7 10.2 (0.4-2.2 kW) GD100-2R2G-SS2-PV GD100-0R4G-S2-PV -S2 model GD100-0R7G-S2-PV 0.75 1PH 220V...

  • Page 9: Installation Guidelines

    Goodrive100-PV Series Solar Pumping VFD Installation guidelines 3 Installation guidelines The chapter describes the mechanical installation and electric installation.  Only qualified electricians are allowed to carry out what described in this chapter. Please operate as the instructions in Safety precautions.
  • Page 10 The VFD should be installed on an upright position to ensure direction sufficient cooling effect. Note: Goodrive100-PV series VFDs should be installed in a clean and ventilated environment  according to enclosure classification. Cooling air must be clean, free from corrosive materials and electrically conductive dust.

  • Page 11: Standard Wiring

    Goodrive100-PV Series Solar Pumping VFD Installation guidelines a) Wall mounting b) Rail mounting Figure 3-1 Installation manners Note: The minimum space of A and B is 100mm. H is 36.6mm and W is 35.0mm. (2) The VFDs ≥ 4kW support wall mounting and flange mounting.
  • Page 12 Goodrive100-PV Series Solar Pumping VFD Installation guidelines PV input Forced switch to mains 1PH/2PH algorithm shifting Common terminal High water level switch GD100-PV Low water level switch Common terminal Well Water tower Water pump Figure 3-3 Standard wiring diagram  The DC breaker Q1 must be installed as the protection switch for PV input.
  • Page 13 Goodrive100-PV Series Solar Pumping VFD Installation guidelines Terminal Name Function R, S, T 3PH (1PH) AC input terminals, connected to the grid AC input (L, N) Note: Use the screws equipped with the VFD for wiring. (+), (-) PV input...
  • Page 14 Goodrive100-PV Series Solar Pumping VFD Installation guidelines U1 and V1 are the common terminals of the windings. Connect them to the output terminal W of the solar pumping VFD. Connect U2 to the output terminal U of the VFD. Connect V2 to the output terminal V of the VFD.
  • Page 15 Goodrive100-PV Series Solar Pumping VFD Installation guidelines Terminal Category Terminal name Terminal function symbol frequency, switching-off indicates input controlled by the keypad.) connects high-water switch normally open contact Single/two phase default. algorithm connects switching low-water switch normally closed contact. S4: A high electrical level corresponds single-phase algorithm.

  • Page 16: Keypad Operation Procedure

    Goodrive100-PV Series Solar Pumping VFD Keypad operation procedure 4 Keypad operation procedure 4.1 Keypad introduction Keypads are used to control GD100-PV series VFDs, read the state data and adjust parameters. If it is necessary to connect the keypad to other external device, you can use the standard RJ45 cable with crystal head as the external extension cable.
  • Page 17 Goodrive100-PV Series Solar Pumping VFD Keypad operation procedure Serial Name Description LED off means that the VFD is in the stopping state; LED blinking means the RUN/TUNE VFD is in the parameter autotune state; LED on means the VFD is in the running state.
  • Page 18 Goodrive100-PV Series Solar Pumping VFD Keypad operation procedure Serial Name Description Display Mean Display Mean Display Mean Display Mean Programming Enter or escape from the first level menu and remove the parameter quickly. Enter the menu step-by-step. DATA Entry key Confirm parameters.

  • Page 19: Keypad Displaying

    Goodrive100-PV Series Solar Pumping VFD Keypad operation procedure 4.2 Keypad displaying The keypad displaying state of GD100-PV series VFDs is divided into stopping state parameter, running state parameter, function code parameter editing state and fault alarm state and so on.

  • Page 20: Keypad Operation

    Goodrive100-PV Series Solar Pumping VFD Keypad operation procedure RUN/TUNE FWD/REV LOCAL/REMOT TRIP RUN/TUNE FWD/REV LOCAL/REMOT TRIP RUN/TUNE FWD/REV LOCAL/REMOT TRIP Figure 4-3 Displayed state 4.3 Keypad operation Operate the VFD via operation panel. See the detailed structure description of function codes in the brief diagram of function codes.
  • Page 21 Goodrive100-PV Series Solar Pumping VFD Keypad operation procedure 4.3.2 How to set the password of the VFD GD100-PV series VFDs provide password protection function to users. Set P07.00 to gain the password and the password protection becomes valid instantly after quitting from the function code editing state.

  • Page 22: Commissioning Guidelines

    Goodrive100-PV Series Solar Pumping VFD Commissioning guidelines 5 Commissioning guidelines  Disconnect all power supplies applied to the VFD before the terminal wiring and wait for at least the designated time after disconnecting the power supply.  High voltage is present inside the VFD during running. Do not carry out any operation except for the keypad setting.
  • Page 23 Goodrive100-PV Series Solar Pumping VFD Commissioning guidelines the motor is bigger. In reserve, the lower the water yield is, the more stable the motor frequency is. 5.4.2 Special settings for single phase motors a) When the single phase motor is in bad running performance, the user can adjust P04 VF curve settings: set P04.00=1 and set P04.03–P04.08 to appropriate values according to...

  • Page 24: Function Parameters

    Goodrive100-PV Series Solar Pumping VFD Function parameters 6 Function parameters ○ “ ”: means the set value of the parameter can be modified on stop and running state; “◎”: means the set value of the parameter cannot be modified on the running state;...
  • Page 25 Goodrive100-PV Series Solar Pumping VFD Function parameters Function Name Detailed illustration of parameters Default Modify code includes: start, stop, forward/reverse rotating, jogging and fault reset. 0: Keypad running command channel (“LOCAL/REMOT” light off) Carry out the command control by RUN, STOP/RST on the keypad.
  • Page 26 Goodrive100-PV Series Solar Pumping VFD Function parameters Function Name Detailed illustration of parameters Default Modify code The upper limit of the running frequency is the upper limit of the output frequency of the VFD which is lower than or equal to Upper limit of the P00.04...
  • Page 27 Goodrive100-PV Series Solar Pumping VFD Function parameters Function Name Detailed illustration of parameters Default Modify code selection runs in the forward direction. FWD/REV indicator is off. 1: Runs at the opposite direction. The VFD runs in the reverse direction. FWD/REV indicator is on.
  • Page 28 Goodrive100-PV Series Solar Pumping VFD Function parameters Function Name Detailed illustration of parameters Default Modify code autotuning when high control accuracy is needed. 2: Static autotuning It is suitable in the cases when the motor cannot de-couple form the load. The autotuning for the motor parameter will impact the control accuracy.
  • Page 29 Goodrive100-PV Series Solar Pumping VFD Function parameters Function Name Detailed illustration of parameters Default Modify code immediately. And the load coasts to stop at the mechanical inertia. 0: The terminal running command is Operation invalid when powering on. P01.18 ○...
  • Page 30 Goodrive100-PV Series Solar Pumping VFD Function parameters Function Name Detailed illustration of parameters Default Modify code name plate. In order to ensure the controlling performance, please configure motor according standard principles, if the gap between the motor and the standard...
  • Page 31 Goodrive100-PV Series Solar Pumping VFD Function parameters Function Name Detailed illustration of parameters Default Modify code Mutual inductance features. Depend P02.09 ○ of asynchronous 0.1–6553.5mH Note: Users cannot on model motor modify the parameters freely. Non-load current Depend P02.10 of asynchronous 0.1–6553.5A...
  • Page 32 Goodrive100-PV Series Solar Pumping VFD Function parameters Function Name Detailed illustration of parameters Default Modify code change the feature of the curve. Note: V in the below picture is the motor rated voltage and f is the motor rated frequency.
  • Page 33 Goodrive100-PV Series Solar Pumping VFD Function parameters Function Name Detailed illustration of parameters Default Modify code Output voltage Output boost frequency Cut-off Setting range P04.01: 0.0%: (automatic) 0.1%–10.0% Setting range of P04.02: 0.0%–50.0% If P04.00 =1, the user can set V//F curve V/F frequency by P04.03–P04.08.
  • Page 34 Goodrive100-PV Series Solar Pumping VFD Function parameters Function Name Detailed illustration of parameters Default Modify code (rated frequency of motor1) or P04.05– P02.16 (rated frequency of motor1) Setting range of P04.08: 0.0%–110.0% (rated voltage of motor1) This function code is used to compensate...
  • Page 35 Goodrive100-PV Series Solar Pumping VFD Function parameters Function Name Detailed illustration of parameters Default Modify code 1: HDI switch input S1 terminals 0: No function P05.01 ◎ function selection 1: Forward rotation operation 2: Reverse rotation operation S2 terminals P05.02 ◎...
  • Page 36 Goodrive100-PV Series Solar Pumping VFD Function parameters Function Name Detailed illustration of parameters Default Modify code 25: PID control pause 26: Traverse pause (stop at the current frequency) 27: Traverse reset (return to the center frequency) 28: Counter reset 29: Torque control prohibition...
  • Page 37 Goodrive100-PV Series Solar Pumping VFD Function parameters Function Name Detailed illustration of parameters Default Modify code 46: PV voltage digital input when no boost module is applied (in auto switching mode) 47–63: Reserved Polarity selection 0x000–0x10F P05.10 0x000 BIT8 BIT3...
  • Page 38 Goodrive100-PV Series Solar Pumping VFD Function parameters Function Name Detailed illustration of parameters Default Modify code 20: External fault valid 21: Reserved 22: Running time arrival Modbus communication virtual terminals output 24–26: Reserved 27: Weak light 28–29: Reserved 30: Shift to PV mode (If the system works in PV mode, relay output is high.)
  • Page 39 Goodrive100-PV Series Solar Pumping VFD Function parameters Function Name Detailed illustration of parameters Default Modify code P07 Group Human-Machine Interface 0: No function 1: Jogging running. Press QUICK/JOG to begin the jogging running. 2: Shift the display state by the shifting key.
  • Page 40 Goodrive100-PV Series Solar Pumping VFD Function parameters Function Name Detailed illustration of parameters Default Modify code When P07.02=6, shifting sequence of running command channels. Keypad control→terminal control QUICK/JOG the →communication control shifting sequence P07.03 1: Keypad control←→terminals control ○ of running Keypad control←→communication...
  • Page 41 Goodrive100-PV Series Solar Pumping VFD Function parameters Function Name Detailed illustration of parameters Default Modify code power VFD power consumption = P07.15*1000 + consumption P07.16 Setting range of P07.15: 0–65535 (*1000) LSB of VFD P07.16 Setting range of P07.16: 0.0–999.9 power ●...
  • Page 42 Goodrive100-PV Series Solar Pumping VFD Function parameters Function Name Detailed illustration of parameters Default Modify code Previous 12 fault 22: PID response offline fault (PIDE) P07.63 ● type 23: Braking unit fault (bCE) 24: Running time arrival (END) Previous 13 fault P07.64...

  • Page 43: Parameters Of Special Functions

    Goodrive100-PV Series Solar Pumping VFD Function parameters Function Name Detailed illustration of parameters Default Modify code Full water alarm (A-tF) Water-empty alarm (A-tL) P08 Group Enhanced functions Times of fault P08.28 ○ 0–10 reset Interval time of P08.29 automatic fault 10.0s...
  • Page 44 Goodrive100-PV Series Solar Pumping VFD Function parameters Function Name Detailed illustration of parameters Default Modify code sudden power loss Setting range: 0.00Hz–P00.03/s After the power loss of the grid, the bus voltage drops to the sudden frequency decrease point, the VFD begin to decrease the running frequency at P11.02, to make the VFD generate...
  • Page 45 Goodrive100-PV Series Solar Pumping VFD Function parameters Function Name Detailed illustration of parameters Default Modify code of Max. power tracking. The voltage is changing until the system is stable. Note: If terminal 43 is valid, the function is invalid. 0.0–6553.5 V DC If P15.01 is 0, the reference voltage is...
  • Page 46 Goodrive100-PV Series Solar Pumping VFD Function parameters Function Name Detailed illustration of parameters Default Modify code 0.0%–P15.04 (100.0% corresponds to P00.03) P15.05 is used to limit the Min. value of Lower frequency target frequency, 100.0% P15.05 20.0% ○ of PI output corresponds to P00.03.
  • Page 47 Goodrive100-PV Series Solar Pumping VFD Function parameters Function Name Detailed illustration of parameters Default Modify code 0.0–6553.5Vdc If the absolute value of bus voltage minus the reference value is bigger than P15.10 PI switching point 20.0V ◎ P15.10, it will switch to P15.08 and P15.09;...
  • Page 48 Goodrive100-PV Series Solar Pumping VFD Function parameters Function Name Detailed illustration of parameters Default Modify code P15.17. If the function code is 1–3, it is the reference of water-level control analog signal. For details, see P15.12 and P12.13. 0.0–100.0% This code is valid when P15.11 water level control is based on analog input.
  • Page 49 Goodrive100-PV Series Solar Pumping VFD Function parameters Function Name Detailed illustration of parameters Default Modify code timing will clear automatically. 0.0–100.0% This code is valid when P15.11 water level control is based on analog input. If the detected water level control analog signal is greater than the water level threshold P15.13 and keeps in the...
  • Page 50 Goodrive100-PV Series Solar Pumping VFD Function parameters Function Name Detailed illustration of parameters Default Modify code 0–10000s Time setting of wake-up delay in Wake-up delay in P15.15 full-water state (This function code is ○ full water state still valid when the digital indicates the full-water signal.)
  • Page 51 Goodrive100-PV Series Solar Pumping VFD Function parameters Function Name Detailed illustration of parameters Default Modify code underload detection of the pumping VFD. If it is not 0.0%, it is determined by P15.20. 100.0% corresponds to the rated current of the motor.
  • Page 52 Goodrive100-PV Series Solar Pumping VFD Function parameters Function Name Detailed illustration of parameters Default Modify code for the analysis of underload operation. If the target frequency and the absolute value of the ramp frequency is less than or equal to P15.22, the current will be compared.
  • Page 53 Goodrive100-PV Series Solar Pumping VFD Function parameters Function Name Detailed illustration of parameters Default Modify code Initial reference P15.25 0.0–2000.0V ● voltage display 0.00–1.00 This function code is used to set the minimum voltage reference during maximum power tracking. Min. voltage reference during max.
  • Page 54 Goodrive100-PV Series Solar Pumping VFD Function parameters Function Name Detailed illustration of parameters Default Modify code 0.0–200.0V Adjustment of MPPT begins to change from the P15.28 5.0V initial reference reference voltage ○ voltage Initial reference voltage voltage-P15.28 0.0–10.0s When P15.29 is set to 0.0, the automatic adjustment is invalid.
  • Page 55 Goodrive100-PV Series Solar Pumping VFD Function parameters Function Name Detailed illustration of parameters Default Modify code 0: Automatic shift 1: Power frequency input 2: PV input If the value is 0, the system will switch between PV input and power frequency...
  • Page 56 Goodrive100-PV Series Solar Pumping VFD Function parameters Function Name Detailed illustration of parameters Default Modify code set by P15.24. To prevent frequent switching, this threshold must greater than P15.33. If the value is 0.0, it is invalid. The default value depends on model.
  • Page 57 Goodrive100-PV Series Solar Pumping VFD Function parameters Function Name Detailed illustration of parameters Default Modify code factory delivery) as model -2, P15.39 must be set to 2. 0: -SS2 220V; single-phase input; single-phase output 1: -S2 220V; single-phase input; three-phase output 220V;...
  • Page 58 Goodrive100-PV Series Solar Pumping VFD Function parameters Function Name Detailed illustration of parameters Default Modify code min. reference reference during maximum power voltage tracking. It equals the solar cell panel open-circuit voltage multiplied P15.26. It is transferred from the boost module.
  • Page 59 Goodrive100-PV Series Solar Pumping VFD Function parameters Function Name Detailed illustration of parameters Default Modify code Setting this value to 1 can reset the total pump flow. P18.13 and P18.14 will Total pump flow P18.15 accumulate the flow after resetting.
  • Page 60 Goodrive100-PV Series Solar Pumping VFD Function parameters Function Name Detailed illustration of parameters Default Modify code voltage loop uses this group parameter. Otherwise, the boost voltage loop uses the first group PI parameter. Setting range: 0.000–65.535 If the difference between the bus...

  • Page 61: Fault Diagnosis And Solution

    Goodrive100-PV Series Solar Pumping VFD Fault diagnosis and solution 7 Fault diagnosis and solution Do as follows after the VFD encounters a fault: 1. Check to ensure there is nothing wrong with the keypad. If not, please contact with the local office.
  • Page 62 Goodrive100-PV Series Solar Pumping VFD Fault diagnosis and solution Fault Fault type Possible cause Solutions code 2. The voltage of the grid is 3. Select the VFD with a larger DEC overcurrent too low. power. 3. The power of the VFD is 4.
  • Page 63 Goodrive100-PV Series Solar Pumping VFD Fault diagnosis and solution Fault Fault type Possible cause Solutions code phase of the load) Rectifier overheat 1. Air duct jam or fan damage 1. Dredge the wind channel or 2. Ambient temperature is too change the fan.
  • Page 64 Goodrive100-PV Series Solar Pumping VFD Fault diagnosis and solution Fault Fault type Possible cause Solutions code 2. Damage to EEPROM panel. 1. Check the PID feedback 1. PID feedback is offline. signal 2. The PID feedback source PIDE PID feedback fault 2.
  • Page 65 Goodrive100-PV Series Solar Pumping VFD Fault diagnosis and solution Fault Fault type Possible cause Solutions code according to the set value. Hydraulic probe Change the damaged hydraulic Hydraulic probe damage damage probe. Change the wiring direction of PV reverse positive...
  • Page 66 Goodrive100-PV Series Solar Pumping VFD Fault diagnosis and solution Fault Fault type Possible cause Solutions code is insufficient. strong. Check whether the solar cell panel configuration is proper. A-LL Underload alarm The reservoir is empty. Check the reservoir. If the user has set the full-water...

  • Page 67: Appendix A Options And Use

    Goodrive100-PV Series Solar Pumping VFD Options and use Appendix A Options and use A.1 Boost module The pumping VFDs ≤ 2.2KW support the installation of the boost module (PP100-3R2-PV) to improve the utilization of the solar modules. The figure below shows the wiring method.

  • Page 68: Gprs Module And Monitoring App

    Goodrive100-PV Series Solar Pumping VFD Options and use Instruction of LEDs Display state Description The boost module has been powered on, and the control Green LED flickering circuit is working. Green LED on The boost module is running. Red LED on The boost module is faulty.

  • Page 69: Cables

    Goodrive100-PV Series Solar Pumping VFD Options and use A.3 Cables A.3.1 Power cables Dimension the input power and motor cables according to local regulations. Note: A separate PE conductor is required if the conductivity of the cable shield is not sufficient for the purpose.
  • Page 70 Goodrive100-PV Series Solar Pumping VFD Options and use Recommended cable size Tightening Terminal torque Model screw (Nm) (+)/(-), R/S/T, U/V/W GD100-2R2G-2-PV 1.2–1.5 GD100-7R5G-4-PV 2–2.5 GD100-004G-2-PV 2–2.5 GD100-011G-4-PV 2–2.5 GD100-5R5G-2-PV 2–2.5 GD100-015G-4-PV 2–2.5 GD100-7R5G-2-PV 2–2.5 GD100-018G-4-PV 2–2.5 GD100-022G-4-PV 2–2.5 GD100-030G-4-PV 4–6 GD100-037G-4-PV 4–6...

  • Page 71: Reactors

    Goodrive100-PV Series Solar Pumping VFD Options and use A.4 Reactors When the distance between the VFD and motor is longer than 50 m, the parasitic capacitance between the long cable and ground may cause large leakage current, and overcurrent protection of the VFD may be frequently triggered. To prevent this from happening and avoid damage to the motor insulator, compensation must be made by adding an output reactor.

  • Page 72: Filters

    Goodrive100-PV Series Solar Pumping VFD Options and use VFD power Output reactor GD100-090G-4-PV OCL2-110-4 GD100-110G-4-PV OCL2-110-4 GD100-132G-4-PV OCL2-160-4 GD100-160G-4-PV OCL2-200-4 GD100-185G-4-PV OCL2-200-4 GD100-200G-4-PV OCL2-200-4 Note:  The rated derate voltage of the output reactor is 1%±15%.  Above options are external, and the customer should specify the model when purchasing.

  • Page 73: Appendix B Recommended Solar Modules

    Goodrive100-PV Series Solar Pumping VFD Recommended solar modules Appendix B Recommended solar modules B.1 Recommended configuration for solar pumping VFDs Open-circuit voltage degree of solar module 37±1V 45±1V Solar pumping VFD model Modules per Module Module Modules per string * power±5Wp...

  • Page 74: Recommended Configuration For Vfds With The Boost Module

    Goodrive100-PV Series Solar Pumping VFD Recommended solar modules Open-circuit voltage degree of solar module 37±1V 45±1V Solar pumping VFD model Modules per Module Module Modules per string * power±5Wp power±5Wp string * strings strings GD100-090G-4-PV 18*22 15*22 GD100-110G-4-PV 18*27 15*27...

  • Page 75: Appendix C Power Frequency & Pv Switching Solution

    Goodrive100-PV Series Solar Pumping VFD Power frequency & PV switching solution Appendix C Power frequency & PV switching solution C.1 Solution introduction Generally, VFDs do not allow simultaneous connection to power frequency and PV. If such simultaneous connection is required, switching control circuit must be configured externally.
  • Page 76 Goodrive100-PV Series Solar Pumping VFD Power frequency & PV switching solution Sign Description Remarks current 110A: applies to VFDs 18.5–37kW Voltage 4: AC 3PH 380V (-15%)–440 (+10%) Voltage degree ① degree 2: AC 3PH 220V (-15%)–240 (+10%) Industrial Industrial code PV stands for solar pumping.
  • Page 77 Goodrive100-PV Series Solar Pumping VFD Power frequency & PV switching solution C.1.2 Model selection reference for low-voltage apparatus Diode Model breaker breaker contactor Fuse GD100-0R4G-S2-PV-AS GD100-0R7G-S2-PV-AS GD100-0R4G-SS2-PV-AS GD100-1R5G-2-PV-AS GD100-1R5G-S2-PV-AS GD100-0R7G-SS2-PV-AS 25A/16 16A/ GD100-2R2G-S2-PV-AS 1000VDC GD100-1R5G-SS2-PV-AS GD100-2R2G-SS2-PV-AS GD100-0R7G-4-PV-AS GD100-1R5G-4-PV-AS Type GD100-2R2G-4-PV-AS Ⅱ,...
  • Page 78 Goodrive100-PV Series Solar Pumping VFD Power frequency & PV switching solution Diode Model breaker breaker contactor Fuse 160A/ 160A/ GD100-045G-4-PV-AS 1000VDC 1600V GD100-055G-4-PV-AS 250A/ 250A/ 1000VDC 1600V GD100-075G-4-PV-AS GD100-090G-4-PV-AS 350A/ 350A/ 1000VDC 1600V GD100-110G-4-PV-AS 400A/ 400A/ GD100-132G-4-PV-AS 1000VDC 1600V GD100-160G-4-PV-AS...

  • Page 79: Ip54 Protection-Level Vfds

    Goodrive100-PV Series Solar Pumping VFD Power frequency & PV switching solution C.2 IP54 protection-level VFDs Our company provides IP54 protection-level VFDs, which are divided into two types: One type implements auto power frequency & PV switching and the other type does not implement auto switching.

  • Page 80: Wiring Terminals

    Goodrive100-PV Series Solar Pumping VFD Power frequency & PV switching solution Power (kW) Model GD100-004G-45-PV-AS GD100-004G-25-PV-AS GD100-2R2G-45-PV-AS GD100-2R2G-S25-PV-AS GD100-2R2G-SS25-PV-AS GD100-1R5G-45-PV-AS GD100-1R5G-S25-PV-AS GD100-1R5G-SS25-PV-AS GD100-0R7G-45-PV-AS 0.75 GD100-0R7G-S25-PV-AS GD100-0R7G-SS25-PV-AS GD100-0R4G-S25-PV-AS GD100-0R4G-SS25-PV-AS Note:  The VFDs that do not implement auto switching do not have the suffix -AS.

  • Page 81: Parameter Setting Method

    Goodrive100-PV Series Solar Pumping VFD Power frequency & PV switching solution Figure C-4 Wiring terminals of -4 models for VFDs ≤2.2kW Figure C-5 Wiring terminals of -S2/-SS2 models for VFDs ≤2.2kW Wiring terminal functions Terminal Name Function 3PH 380/220V AC input terminals, connected to the grid R, S, T Neutral wire.

  • Page 82: Appendix D Dimension Drawings

    Goodrive100-PV Series Solar Pumping VFD Dimension drawings Appendix D Dimension drawings D.1 External keypad structure Keypad structure Installation hole Note: The external keypad is optional for the VFDs (380V; ≤2.2kW) and the standard keypad of VFDs (380V; ≥4kW) can be used as the external keypad.

  • Page 83: Dimensions Of 0.4-2.2Kw Models

    Goodrive100-PV Series Solar Pumping VFD Dimension drawings D.2 Dimensions of 0.4-2.2kW models (a) Wall mounting Dimensions in wall mounting (unit: mm) Installation Model hole (d) GD100-0R4G-S2-PV 80.0 60.0 160.0 150.0 123.5 120.3 GD100-0R7G-S2-PV 80.0 60.0 160.0 150.0 123.5 120.3 GD100-0R4G-SS2-PV 80.0...
  • Page 84 Goodrive100-PV Series Solar Pumping VFD Dimension drawings (b) Rail mounting Dimensions in rail mounting (unit: mm) Installation Model hole (d) GD100-0R4G-S2-PV 80.0 160.0 35.4 36.6 123.5 120.3 GD100-0R7G-S2-PV 80.0 160.0 35.4 36.6 123.5 120.3 GD100-0R4G-SS2-PV 80.0 160.0 35.4 36.6 123.5 120.3...

  • Page 85: Dimensions Of 1.5-200Kw Models

    Goodrive100-PV Series Solar Pumping VFD Dimension drawings D.3 Dimensions of 1.5-200kW models (a) Wall mounting Dimensions in wall mounting (unit: mm) Installation Model hole (d) GD100-1R5G-2-PV 146.0 131.0 256.0 243.5 167.0 84.5 GD100-2R2G-2-PV 146.0 131.0 256.0 243.5 167.0 84.5 GD100-004G-4-PV 146.0...
  • Page 86 Goodrive100-PV Series Solar Pumping VFD Dimension drawings Installation Model hole (d) GD100-075G-4-PV 282.0 160.0 560.0 542.4 238.0 138.0 GD100-090G-4-PV 338.0 200.0 554.0 534.0 326.2 GD100-110G-4-PV 338.0 200.0 554.0 534.0 326.2 GD100-132G-4-PV 500.0 360.0 870.0 850.0 360.0 GD100-160G-4-PV 500.0 360.0 870.0 850.0...
  • Page 87 Goodrive100-PV Series Solar Pumping VFD Dimension drawings Installation Model W1 W2 W3 W4 H1 hole specs GD100-7R5G-2-PV 191.2 151 174 11.5 370 351 324 12 196.3 113 GD100-018G-4-PV 266 250 224 13 371 250 350.6 20.3 184.6 104 GD100-022G-4-PV 266 250 224 13 371 250 350.6 20.3 184.6 104 GD100-030G-4-PV 316 300 274 13 430 300 410 202 118.3...

  • Page 88: Appendix E Further Information

    Goodrive100-PV Series Solar Pumping VFD Further information Appendix E Further information E.1 Product and service inquiries Address any inquiries about the product to your local offices, quoting the type designation and serial number of the unit in question.
  • Page 89 6 6 0 0 1 - 0 0 4 3 0 6 6 0 0 1 - 0 0 4 4 5 201908 (V1.1) 201905 (V1.1...
