Goodrive350-19 Series VFD for Crane
Function description
Smooth lifting
Instant stop at
load change
Set frequency
exception
protection
Motor overheating
protection
Terminal analog
input resolution
Terminal digital
input resolution
Analog input
Analog output
Digital input
Peripheral
interface
Digital output
Relay output
Extended
interfaces
start, run, and stop at the preset running frequency and time
according to the settings. During the process, the brake can be
normally opened or closed under the control of VFD, ensuring
the stability without hook slip or exception when the crane starts
or stops.
In high-speed lifting mode, the high speed is limited at the
moment of steel rope straightening, reducing the impact caused
by the sudden load to the crane at the lifting start.
In the process of upward lifting, if the hook is abnormally hung, it
can quickly stop the machine and instantly eliminate the potential
safety hazards.
If the set frequency is lower than the threshold after the brake is
opened, the VFD reports the set frequency exception, which
prevents slip caused by insufficient force at low speed.
An I/O expansion card can receive the input from a motor
temperature sensor (PT100, PT1000, or PTC); at the same time,
AI analog can also receive the input from a motor temperature
sensor (PT100, PT1000, KTY84, or PTC), for motor overheating
protection.
No more than 20mV
No more than 2ms
Two inputs; AI1: 0–10V/0–20mA; AI2: -10–10V
One input; AO1: 0–10V/0–20mA
Four regular inputs; max. frequency: 1kHz; internal impedance:
3.3kΩ
Two high-speed inputs; max. frequency: 50kHz; supporting
quadrature encoder input; with speed measurement function
One high-speed pulse output; max. frequency: 50kHz
One Y terminal open collector output
Two programmable relay outputs
RO1A: NO; RO1B: NC; RO1C: common
RO2A: NO; RO2B: NC; RO2C: common
Contact capacity: 3A/250VAC, 1A/30VDC
SLOT1, SLOT2, and SLOT3
Supporting PG cards, programmable expansion cards,
communication cards, I/O cards and so on
